Запчасти Komatsu GD655-5 ТРАНСМИССИЯ, ПЕРЕД. ВЫС. И 1 SPEED МУФТА ТРАНСМИССИЯ

|1

23B-13-70000

Transmission Assembly

SN: B40001-UP

1шт.

|1

23B-15-72020

Clutch Assembly

SN: B40001-UP

1шт.

|1

23B-15-72121

Shaft and Cylinder Assembly

SN: B40001-UP

1шт.

1

Shaft,Upper

SN: B40001-UP

1шт.

2

56D-15-29790

Plug

SN: B40001-UP

2шт.

3

23B-15-72920

Orifice

SN: B40001-UP

1шт.

4

Housing

SN: B40001-UP

1шт.

5

714-23-12651

Piston

SN: B40001-UP

1шт.

6

23B-15-72670

Piston

SN: B40001-UP

1шт.

7

04020-00514

Pin, Dowel

SN: B40001-UP

2шт.

8

362-15-19520

Ring, Snap

SN: B40001-UP

1шт.

9

714-23-12690

Piston, Range

SN: B40001-UP

1шт.

10

419-15-12140

Ring, Snap

SN: B40001-UP

2шт.

11

714-12-19711

Disc, T=2.2mm

SN: B40001-UP

17шт.

12

714-16-19730

Plate, T=1.7mm, Separate

SN: B40001-UP

19шт.

13

56D-15-12710

Spring, Wave

SN: B40001-UP

17шт.

14

714-12-12610

Plate, End

SN: B40001-UP

2шт.

15

714-08-19220

Seal Ring, (Kit : K01)

SN: B40001-UP

1шт.

16

714-16-19220

Seal Ring, (Kit : K01)

SN: B40001-UP

1шт.

17

714-07-19320

Seal Ring, (Kit : K01)

SN: B40001-UP

2шт.

18

714-08-19560

Washer, Thrust

SN: B40001-UP

2шт.

19

714-08-19570

Washer, Thrust

SN: B40001-UP

1шт.

20

419-15-12640

Bearing

SN: B40001-UP

1шт.

21

419-15-12650

Washer, Thrust

SN: B40001-UP

1шт.

22

714-12-12760

Washer

SN: B40001-UP

1шт.

23

714-23-19631

Bushing,1st

SN: B40001-UP

1шт.

24

714-23-19410

Bearing, Needle

SN: B40001-UP

1шт.

25

714-12-12740

Spacer

SN: B40001-UP

1шт.

26

714-23-19320

Bearing

SN: B40001-UP

1шт.

27

23B-15-72430

Gear, Forward High

SN: B40001-UP

1шт.

28

714-23-12441

Gear,1st

SN: B40001-UP

1шт.

29

04066-00062

Ring, Snap, for Shaft Side

SN: B40001-UP

1шт.

30

714-12-39230

Seal Ring, (Kit : K01)

SN: B40001-UP

3шт.
