|1
707-02-00100
Cylinder Assembly
SN: B40001-UP
2шт.
1
707-12-80230
Cylinder
SN: B40001-UP
1шт.
2
02896-11009
O-ring, (Kit : K10)
SN: B40001-UP
2шт.
3
707-58-50J00
Rod
SN: B40001-UP
1шт.
4
07138-00980
Cap
SN: B40001-UP
1шт.
5
07139-00905
Shim, T=0.5mm
SN: B40001-UP
2шт.
|5
07139-00902
Shim, T=0.2mm
SN: B40001-UP
3шт.
6
07141-00090
Seal, Dust, (Kit : K10)
SN: B40001-UP
1шт.
7
07020-00900
Fitting, Grease
SN: B40001-UP
1шт.
8
01010-82075
Bolt
SN: B40001-UP
2шт.
9
01643-32060
Washer
SN: B40001-UP
2шт.
10
01580-12016
Nut
SN: B40001-UP
2шт.
11
707-29-80740
Head, Cylinder
SN: B40001-UP
1шт.
12
707-56-50740
Seal, Dust, (Kit : K10)
SN: B40001-UP
1шт.
13
07179-12062
Ring, Snap
SN: B40001-UP
1шт.
14
707-51-50211
Packing, Rod, (Kit : K10)
SN: B40001-UP
1шт.
15
707-52-15230
Bushing
SN: B40001-UP
1шт.
16
07000-12080
O-ring, (Kit : K10)
SN: B40001-UP
1шт.
17
07000-12075
O-ring, (Kit : K10)
SN: B40001-UP
1шт.
18
07146-02076
Ring, Back-up, (Kit : K10)
SN: B40001-UP
1шт.
19
707-36-80070
Piston
SN: B40001-UP
1шт.
20
707-44-80180
Ring, Piston, (Kit : K10)
SN: B40001-UP
1шт.
21
07156-00810
Ring, Wear, (Kit : K10)
SN: B40001-UP
1шт.
22
707-67-27030
Nut
SN: B40001-UP
1шт.
23
707-86-01090
Tube
SN: B40001-UP
2шт.
24
02896-11009
O-ring, (Kit : K10)
SN: B40001-UP
2шт.
25
01010-81020
Bolt
SN: B40001-UP
2шт.
26
01643-31032
Washer
SN: B40001-UP
2шт.
