1
23B-07-62132
TUBE,(SEE FIG. K1110-27A0)
SN: 51544-UP
1шт.
1
0
TUBE,(SEE FIG. K1110-27A0)
SN: 51501-51543
1шт.
2
56E-07-21133
CONDENSER ASS'Y,(SEE FIG. C0110-02A0)
SN: 51501-UP
1шт.
3
23B-07-63112
PANEL,(SEE FIG. K0210-19A0)
SN: 53023-UP
1шт.
3
0
PANEL,(SEE FIG. K0210-19A0)
SN: 51501-53022
1шт.
4
23B-07-61112
COMPRESSOR,(SEE FIG. K0710-01A0)
SN: 51501-UP
1шт.
5
423-07-31571
RECEIVER DRYER,(SEE FIG. K0710-01A0)
SN: 51501-UP
1шт.
6
23B-07-61291
HOSE, 2585MM,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
7
AN51439-D0051
O-RING
SN: 51501-UP
2шт.
8
23B-07-61321
HOSE, 3400MM,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
9
AN51439-D0041
O-RING
SN: 51501-UP
2шт.
10
23B-07-61331
HOSE, 3120MM,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
11
AN51439-D0031
O-RING
SN: 51501-UP
2шт.
12
23B-07-61311
HOSE, 760MM,(SEE FIG. K0711-02A0)
SN: 51501-UP
1шт.
13
AN51439-D0031
O-RING
SN: 51501-UP
2шт.
14
23B-07-61440
TUBE,(SEE FIG. K0711-02A0)
SN: 51501-UP
1шт.
15
AN51439-D0031
O-RING
SN: 51501-UP
2шт.
16
23B-07-61450
TUBE,(SEE FIG. K0711-02A0)
SN: 51501-UP
1шт.
17
AN51439-D0041
O-RING
SN: 51501-UP
2шт.
18
23B-07-61430
TUBE,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
19
AN51439-D0051
O-RING
SN: 51501-UP
2шт.
20
23B-07-61370
TUBE,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
21
AN51439-D0041
O-RING
SN: 51501-UP
2шт.
22
23B-07-61360
TUBE,(SEE FIG. K0710-02A0)
SN: 51501-UP
1шт.
23
AN51439-D0031
O-RING
SN: 51501-UP
2шт.
