Запчасти Komatsu GD650A МОСТ ASSEMBLY БЕЗ PLANETARY ПРИВОД TRAIN

|$1

1437 902 H91

AXLE ASSEMBLY - NO SPIN DIFFERENTIAL

1шт.

|$2

OR

-1шт.

|$3

1437 899 H91

AXLE ASSEMBLY - LOCK/UNLOCK DIFFERENTIAL

1шт.

1

24 841 R1

BOLT

8шт.

2

25 534 R1

WASHER, FLAT

16шт.

3

1281 013 H2

DISK, PARKING BRAKE

1шт.

4

30 021 R1

BOLT

5шт.

5

30 176 R1

WASHER, FLAT

5шт.

6

1431 588 H1

BRACKET, PARKING BRAKE

1шт.

7

CALIPER ASSEMBLY, PARKING BRAKE (SEE PG 04-016)

1шт.

8

159 906

GASKET, LIQUID - 300 ML CARTRIDGE

1шт.

9

CASE, DIFFERENTIAL (SEE PG 07-054)

1шт.

|$13

OR

-1шт.

|$14

CASE, DIFFERENTIAL (SEE PG 07-056)

1шт.

10

1277 410 H1

RING, RETAINING

2шт.

11

1286 766 H91

BEARING, SPHERICAL ROLLER

2шт.

12

1286 767 H1

SEAL, OIL

2шт.

13

1435 732 H91

SLEEVE, TANDEM MOUNTING

2шт.

14

1285 337 H1

SEAL, GREASE

2шт.

|$20

1286 765 H91

BEARING ASSEMBLY

2шт.

15

1286 764 H91

BEARING, CONE

1шт.

16

1286 763 H1

BEARING, CUP

1шт.

17

1430 350 H92

HOUSING, FINAL DRIVE - L.H.

1шт.

|$24

1430 351 H92

HOUSING, FINAL DRIVE - R.H.

1шт.

18

30 076 R1

BOLT

24шт.

19

25 547 R1

WASHER, FLAT

24шт.

20

109 461

FITTING, LUBE

2шт.

|$28

625 365 C91

BEARING ASSEMBLY

2шт.

21

625 364 C1

BEARING, CUP

1шт.

22

625 363 C91

BEARING, CONE

1шт.

23

1435 733 H1

SHIM - 0.13 MM

-2шт.

|$32

1435 734 H1

SHIM - 0.18 MM

-2шт.

|$33

1435 735 H1

SHIM - 0.50 MM

-2шт.

24

1435 079 H1

RETAINER, BEARING

2шт.

25

22 422 T1

O-RING

2шт.

26

31 148 R1

BOLT

36шт.

|$37

1286 905 H91

SHAFT ASSEMBLY, AXLE

2шт.

27

1286 906 H1

SLEEVE, OUTPUT SHAFT

1шт.

28

1286 922 H1

SHAFT, AXLE

1шт.

29

1287 274 H1

GEAR, BRAKE PLATE

2шт.

30

1287 273 H1

RING, RETAINING

4шт.

31

621 247 C1

RING, RETAINING

2шт.

32

1287 272 H1

SPROCKET

4шт.

33

1286 819 H1

SPACER, OUTPUT SPROCKET

2шт.

34

19 875 R1

DOWEL, LOCATING

4шт.

35

24 865 R1

BOLT

4шт.

36

25 546 R1

WASHER, FLAT

8шт.

37

25 526 R1

NUT, HEX

4шт.

38

9413 979

NUT, LOCK

8шт.
