Запчасти Komatsu GD650A БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

1294 789 H94

BLOCK ASSY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

1240 888 H1

PLUG, EXPANSION

1шт.

3

1240 891 H1

PLUG, EXPANSION

4шт.

4

1240 889 H1

PLUG, EXPANSION

2шт.

4

1240 154 H3

PLUG, EXPANSION

1шт.

5

1240 154 H3

PLUG, EXPANSION

1шт.

6

1240 933 H1

BUSHING, CAMSHAFT

7шт.

7

1294 791 H1

CAP, MAIN BEARING

7шт.

8

1240 979 H1

PLUG, EXPANSION

4шт.

9

1294 790 H1

BOLT (14x2.00x128)

14шт.

12

1238 127 H1

DRAINCOCK

1шт.

13

1295 788 H1

PLUG, EXPANSION

4шт.

14

1239 159 H1

PLUG, PIPE

1шт.

15

1239 160 H1

PLUG, PIPE

1шт.

16

1239 161 H1

PLUG, PIPE

1шт.

17

1240 128 H1

DOWEL, PIN

2шт.

18

1240 944 H1

DOWEL, PIN

4шт.

19

1240 946 H1

PLUG, EXPANSION

1шт.

20

1294 792 H1

NOZZLE, PISTON COOLING

12шт.

21

1240 370 H1

PLUG, PIPE

6шт.

|$21

1295 708 H91

KIT, LINER

6шт.

10

NSS

LINER, CYLINDER

1шт.

11

1241 196 H1

SEAL, RECTANGULAR RING

1шт.

|$24

1296 603 H2

SHIM, COUNTERBORE SERVICE - 0.010 INCH OS

-2шт.

|$25

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 INCH OS

-2шт.

|$26

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 INCH OS

-2шт.

|$27

1304 946 H1

BUSHING, CAMSHAFT OVERSIZE

-2шт.

|$28

1294 900 H92

KIT, CYLINDER BLOCK

1шт.

|$31

-1шт.

|$30

F1 - INCLUDE IN CYLINDER BLOCK SERVICE KIT 1294 900 H92

-1шт.

|$32

-1шт.
