Запчасти Komatsu GD650A 7/8 INCH MOLDBOARD FT. С MOVEABLE ЦИЛИНДР КРЕПЛЕНИЕ КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1285 849 H91

MOLDBOARD ASSEMBLY - 7/8 IN. X 24 IN. X 14 FT

1шт.

1

1285 854 H91

MOLDBOARD WELDMENT - 14 FT

1шт.

2

45 483 A

BOLT, PLOW - DOME HEAD

28шт.

3

25 537 R1

WASHER, FLAT

32шт.

4

25 528 R1

NUT, HEX

40шт.

5

140 199

BIT, REVERSIBLE END - FOR 5/8 IN. CUTTING EDGE

2шт.

|$6

161 320

BIT, REVERSIBLE END - FOR 3/4 IN. CUTTING EDGE

2шт.

6

45 046

EDGE, CUTTING - 5/8 IN. X 6 IN. X 7 FT

-2шт.

|$8

121 487

EDGE, CUTTING - 5/8 IN. X 8 IN. X 7 FT

-2шт.

|$9

1278 896 H1

EDGE, CUTTING - 5/8 IN. X 6 IN. X 7 FT

-2шт.

|$10

161 319

EDGE, CUTTING - 3/4 IN. X 6 IN. X 7 FT

-2шт.

7

45 484 A

BOLT, PLOW - DOME HEAD

4шт.

8

15 601 R1

BOLT, PLOW - DOME HEAD

8шт.

9

1286 531 H91

MOUNT, CYLINDER

1шт.

|$19

-1шт.

|$15

F1 - NOT INCLUDED IN MOLDBOARD ASSEMBLIES; MUST BE

-1шт.

|$20

-1шт.

|$21

-1шт.

|$18

F2 - HEAT TREATED.

-1шт.

|$22

-1шт.
