Запчасти Komatsu GD650A ТАХОМЕТР УСТАНОВКА INSTRUMENTS

|$0

1258 372 H91

TACHOMETER INSTALLATION

1шт.

1

1252 758 H91

TACHOMETER, ELECTRIC

1шт.

2

121 624 C1

SENSOR, TACHOMETER

1шт.

3

1267 855 H91

SOCKET ASSEMBLY, LAMP

1шт.

|$4

1284 828 H1

BULB

1шт.

4

PANEL ASSEMBLY, INSTRUMENT (SEE PG 11-006)

-29шт.

5

HARNESS, INSTRUMENT PANEL (SEE PG 11-006)

-29шт.

6

HARNESS, ENGINE (SEE PG 08-002)

-29шт.

7

HOUSING, FLYWHEEL (SEE PG E8-006)

-29шт.

|$11

-1шт.

|$10

-1шт.
