Запчасти Komatsu GD650A БЛОКИР./UNБЛОКИР. ДИФФЕРЕНЦ. ИНДИКАТОР INSTRUMENTS

1

BRACKET, CIRCUIT BREAKER (SEE PG 11-002)

-29шт.

2

1109 633 C1

BREAKER, CIRCUIT

1шт.

3

1106 459 C1

BAR, BUSS

1шт.

4

282 437 R91

SWITCH, LOCK/UNLOCK DIFFERENTIAL

1шт.

|$4

1432 068 H1

DECAL - DIFFERENTIAL LOCK

1шт.

5

PANEL ASSEMBLY, INSTRUMENT (SEE PG 11-006)

-29шт.

6

1270 237 H91

LIGHT, PILOT - DIFFERENTIAL LOCK ON - GREEN

1шт.

|$7

274 019

BULB - 24 VOLT

1шт.

|$8

1431 478 H1

WIRE - PILOT LIGHT GROUND

1шт.

|$9

1432 021 H91

HARNESS, LOCK/UNLOCK STEERING CONSOLE

1шт.

|$10

1279 522 H91

DIODE ASSEMBLY

2шт.

|$11

1432 022 H91

HARNESS, LOCK/UNLOCK SWITCH PANEL

1шт.

|$12

1279 522 H91

DIODE ASSEMBLY

2шт.

|$13

935 522 C1

STRAP, TIE

10шт.
