Запчасти Komatsu GD650A SPEEDOMETER/WARNING LIGHT ПАНЕЛЬ INSTRUMENTS

|$0

1433 292 H91

SPEEDOMETER/WARNING LIGHT PANEL INSTALLATION

1шт.

1

1433 185 H1

SPEEDOMETER

1шт.

|$2

27 727 R1

BULB - #464, 24 VOLT

1шт.

2

1433 186 H91

PANEL, WARNING LIGHT

1шт.

|$4

1433 652 H1

BRACKET, MOUNTING

1шт.

|$5

934 946 R1

WASHER, LOCK

2шт.

|$6

933 763 R1

NUT, HEX

2шт.

3

1433 008 H91

PANEL, SPEEDOMETER/WARNING LIGHT

1шт.

4

86 255

SCREW, SELF-TAPPING

4шт.

5

178 378

WASHER, LOCK

4шт.

6

49 329

GROMMET

1шт.

7

HARNESS, STEERING CONSOLE INSTRUMENT PANEL

-1шт.

|$12

(SEE PG 11-007)

1шт.

|$15

-1шт.

|$14

F1 - FOR SPEEDOMETER SENSOR, SEE PG 08-058

-1шт.

|$16

-1шт.
