Запчасти Komatsu GD650A ДВИГАТЕЛЬ ЭЛЕКТРОПРОВОДКА ЭЛЕКТР.

1

ALTERNATOR (SEE PG 17-064)

-29шт.

|$1

24 860 R1

BOLT

1шт.

|$2

25 536 R1

WASHER, FLAT

1шт.

2

1304 818 H1

PULLEY, ALTERNATOR

1шт.

3

1436 862 H91

HARNESS, ENGINE WIRING

a

1шт.

|$5

1437 022 H91

HARNESS, ENGINE WIRING - WITH ALT. DISCONNECT

b

1шт.

4

299 405 C1

CLAMP, CABLE

1шт.

5

1137 360 C2

SWITCH, ENGINE WATER TEMPERATURE

1шт.

6

1216 162 H1

SENDING UNIT, ENGINE WATER TEMPERATURE

1шт.

7

ELBOW, SPECIAL (SEE PG 08-068)

-29шт.

8

141 453 H1

CLAMP, CABLE

2шт.

|$11

25 536 41

WASHER, FLAT

2шт.

9

MOTOR, CRANKING (SEE PG 08-024)

-29шт.

|$13

30 046 R1

BOLT

3шт.

|$14

30 177 R1

WASHER, FLAT

3шт.

10

SENDING UNITS, TRANSMISSION (SEE PG 08-068)

-29шт.

11

299 565 C1

CLAMP, CABLE - MAIN HARNESS

6шт.

|$17

136 055

CLAMP, CABLE - MAIN HARNESS

4шт.

|$18

105 899

STUD, WELD

10шт.

|$19

25 534 R1

WASHER, FLAT

10шт.

|$20

25 522 R1

NUT, HEX

10шт.

12

1437 824 H91

HARNESS, MAIN WIRING

a

1шт.

|$22

1437 021 H91

HARNESS, MAIN WIRING - WITH SPECIAL LIGHTING

b

1шт.

13

130 096

CLAMP, CABLE

1шт.

|$24

25 534 R1

WASHER, FLAT

1шт.

|$25

25 522 R1

NUT, HEX

1шт.

14

FILTER, CONVERTER OIL (SEE PG 07-014)

-29шт.

15

1436 569 H1

SWITCH, ENGINE OIL PRESSURE

1шт.

16

1434 203 H1

DIODE

2шт.

17

1207 387 H1

SWITCH, MAGNETIC

1шт.

|$30

28 488 R1

BOLT

2шт.

|$31

120 392

WASHER, FLAT

2шт.

|$32

25 519 R1

NUT, HEX

2шт.

18

677 161 R93

SENDING UNIT, ENGINE OIL PRESSURE

1шт.

19

299 399 C1

CLAMP, CABLE

1шт.

|$35

37 467

STUD, WELD

1шт.

|$36

25 532 R1

WASHER, FLAT

1шт.

|$37

25 519 R1

NUT, HEX

1шт.

20

SENDING UNIT, ARTICULATION (SEE PG 08-068)

-29шт.

|$41

-1шт.

|$40

-1шт.
