Запчасти Komatsu GD650A ТОПЛИВН. НАСОС ДВОЙН. HORSE POWER ТОПЛИВН. СИСТЕМА

|$0

1270 852 H91

PUMP, 650 DUAL H.P. FUEL

1шт.

1

1241 267 H1

NUT, HEX

1шт.

2

1241 268 H1

WASHER, LOCK

1шт.

3

1241 233 H1

O-RING

1шт.

4

1241 266 H1

GASKET, FEED PUMP

1шт.

5

1241 261 H1

WASHER, SEALING

2шт.

6

1310 346 H1

KEY, WOODRUFF

1шт.

7

1241 260 H1

VALVE, OVERFLOW

1шт.

8

1241 262 H1

PLUG, TIMING

1шт.

9

1241 263 H1

WASHER, SEALING

1шт.

10

1310 347 H1

KEY, WOODRUFF

1шт.

11

1310 348 H1

BOLT

1шт.

12

1296 819 H1

LEVER, SHUTOFF

1шт.

13

1310 349 H1

BOLT

1шт.

14

1296 820 H1

LEVER, CONTROL

1шт.

|$21

-1шт.

|$16

F1 - SERVICE PARTS WILL NOT BE RELEASED FOR THIS ASSEMBLY.

-1шт.

|$22

-1шт.

|$23

-1шт.

|$19

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$20

ASSEMBLIES CATALOG.

-1шт.
