Запчасти Komatsu GD650A ТОПЛИВН. НАСОС ТОПЛИВН. СИСТЕМА

|$0

1295 522 H92

PUMP, FUEL

1шт.

1

1241 260 H1

VALVE, OVERFLOW

1шт.

2

1241 261 H1

WASHER, SEALING

2шт.

3

1241 262 H1

PLUG, TIMING

1шт.

4

1241 263 H1

WASHER, SEALING

1шт.

5

1241 240 H1

LEVER, SHUTOFF VALVE

1шт.

6

1241 264 H1

SPRING, SHUTOFF

1шт.

7

1241 265 H1

HOUSING, RETURN SPRING

1шт.

8

1241 266 H1

GASKET, FEED PUMP COVER

1шт.

9

1241 267 H1

NUT, GEAR RETAINING

1шт.

10

1241 268 H1

WASHER, LOCK

1шт.

11

1241 275 H1

LEVER, CONTROL

1шт.

12

1295 657 H1

SCREW, VENT

1шт.

13

1295 658 H1

WASHER, SEALING

1шт.

14

1295 659 H1

SCREW, VENT

1шт.

15

1295 660 H1

WASHER, SEALING

1шт.

16

1283 365 H1

SEAL, RECTANGULAR RING

1шт.

17

1283 363 H1

COVER, FUEL PUMP

1шт.

18

1307 573 H1

NUT, HEXAGON

1шт.

19

1240 796 H1

LOCKWASHER

1шт.

20

1296 800 H1

WASHER, FLAT

1шт.

21

1307 345 H1

SCREW

1шт.

22

1241 233 H1

O-RING

1шт.

23

1240 010 H1

ELBOW, MALE ADAPTER

1шт.

24

1283 364 H1

ELBOW, MALE ADAPTER

1шт.

25

1241 126 H1

HOSE, FLEXIBLE

1шт.

|$$27

-1шт.

|$27

F1 - SERVICE PARTS WILL NOT BE RELEASED FOR THIS ASSEMBLY.

-1шт.

|$$29

-1шт.

|$$30

-1шт.

|$30

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$31

ASSEMBLIES CATALOG.

-1шт.
