Запчасти Komatsu GD650A ПОРШЕНЬ & ШАТУН БЛОК ЦИЛИНДРОВ

|$0

1240 906 H91

ROD, ENGINE CONNECTING

6шт.

1

NSS

ROD, CONNECTING

1шт.

2

1304 869 H1

BOLT, CONNECTING ROD

2шт.

3

1240 904 H1

NUT, HEX

2шт.

4

1294 833 H1

BUSHING

1шт.

5

1240 913 H1

BEARING, ROD HALF - STD

12шт.

|$6

1240 914 H1

BEARING, ROD HALF - 0.25MM OVERSIZE

12шт.

|$7

1240 915 H1

BEARING, ROD HALF - 0.50MM OVERSIZE

12шт.

|$8

1240 916 H1

BEARING, ROD HALF - 0.75MM OVERSIZE

12шт.

|$9

1240 917 H1

BEARING, ROD HALF - 1.00MM OVERSIZE

12шт.

|$10

1295 691 H91

KIT, ENGINE PISTON

6шт.

6

NSS

PISTON, ENGINE

1шт.

7

1270 034 H1

RING, RETAINING

2шт.

8

1241 748 H92

SET, PISTON RING

1шт.

9

1240 925 H1

PIN, PISTON

6шт.

|$$16

-1шт.

|$16

CYLINDER KIT

-1шт.

|$17

1295 692 H91

KIT, CYLINDER

6шт.

|$18

1241 175 H92

KIT, LINER

1шт.

|$19

1295 691 H91

KIT, ENGINE PISTON

1шт.

|$$21

-1шт.

|$21

F1 - CYLINDER KIT 1295 692 H91 IS USED WITH STANDARD CYLINDER BLOCK

-1шт.

|$22

ESN 44706125 AND DOWN.

-1шт.

|$$24

-1шт.

|$24

F2 - CYLINDER KIT 1295 706 H91 IS USED WITH THICK WALL BLOCK ESN

-1шт.

|$25

44706126 AND UP.

-1шт.

|$$27

-1шт.

|$27

F3 - LINER KIT 1295 708 H91 IS USED WITH THICK WALL BLOCK ESN

-1шт.

|$28

44706126 AND UP.

-1шт.

|$$30

-1шт.

|$30

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$31

ASSEMBLIES CATALOG.

-1шт.
