Запчасти Komatsu GD650A КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

1240 968 H93

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

1240 259 H1

PIN, DOWEL

1шт.

3

6732-21-6150

GEAR, CRANKSHAFT

1шт.

N/I

1241 184 H2

KIT, MAIN BEARING - STD

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 793 H91

KIT, MAIN BEARING - 0.25MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 794 H91

KIT, MAIN BEARING - 0.50MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 795 H91

KIT, MAIN BEARING - 0.67MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 796 H91

KIT, MAIN BEARING - 1.01MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

7

1295 465 H92

SLEEVE, WEAR - FRONT CRANK

1шт.

8

6736-39-1120

SLEEVE, WEAR - REAR CRANK

1шт.

|$37

-1шт.

|$27

OVERSIZE THRUST BEARINGS

-1шт.

|$28

1304 947 H1

BEARING, CRANKSHAFT THRUST - STD JOURNAL DIA,

-1шт.

|$29

0.25MM OVERSIZE THRUST FACE

1шт.

|$30

1304 948 H1

BEARING, CRANKSHAFT THRUST - STD JOURNAL DIA,

-1шт.

|$31

0.50MM OVERSIZE THRUST FACE

1шт.

|$32

1304 949 H1

BEARING, CRANKSHAFT THRUST - 0.50MM OVERSIZE JOURN

-2шт.

|$33

0.50MM OVERSIZE THRUST FACE

1шт.

|$38

-1шт.

|$35

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$36

ASSEMBLIES CATALOG.

-1шт.
