Запчасти Komatsu GD650A INCH MOLDBOARD - GD7-C КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1436 951 H91

MOLDBOARD ASSEMBLY - 1 IN X 24 IN X 12'

1шт.

|$1

1436 950 H91

MOLDBOARD ASSEMBLY - 1 IN X 24 IN X 14'

1шт.

1

1436 918 H91

MOLDBOARD WELDMENT - 12'

1шт.

|$3

1436 919 H91

MOLDBOARD WELDMENT - 14'

1шт.

2

45 490 A

BOLT, PLOW - DOME HEAD

10шт.

3

25 538 R1

WASHER, FLAT

10шт.

4

25 529 R1

NUT, HEX

10шт.

5

1435 187 H1

BIT, REVERSIBLE END - FOR 5/8 IN CUTTING EDGE

2шт.

6

1280 287 H1

EDGE, CUTTING - 5/8 IN X 6 IN X 6' HEAT TREATED

-2шт.

|$9

1280 300 H1

EDGE, CUTTING - 5/8 IN X 6 IN X 7' HEAT TREATED

-2шт.

7

45 490 A

BOLT, PLOW - DOME HEAD

-2шт.

8

25 538 R1

WASHER, FLAT

-2шт.

9

25 529 R1

NUT, HEX

-2шт.

|$16

-1шт.

|$14

F1 - NOT INCLUDED IN MOLDBOARD ASSEMBLIES,

-1шт.

|$15

MUST BE ORDERED SEPARATELY

-1шт.
