Запчасти Komatsu GD650A 7/8 INCH MOLDBOARD КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1285 693 H91

MOLDBOARD ASSEMBLY - 7/8 IN X 24 IN X 12'

1шт.

|$1

1285 847 H91

MOLDBOARD ASSEMBLY - 7/8 IN X 24 IN X 13'

1шт.

|$2

1285 848 H91

MOLDBOARD ASSEMBLY - 7/8 IN X 24 IN X 14'

1шт.

1

1285 479 H91

MOLDBOARD WELDMENT - 12'

1шт.

|$4

1285 852 H91

MOLDBOARD WELDMENT - 13'

1шт.

|$5

1285 853 H91

MOLDBOARD WELDMENT - 14'

1шт.

2

45 483 A

BOLT, PLOW - DOME HEAD

10шт.

3

25 537 R1

WASHER, FLAT

10шт.

4

25 528 R1

NUT, HEX

10шт.

5

140 199

BIT, REVERSIBLE END - FOR 5/8 IN CUTTING EDGE

2шт.

|$10

161 320

BIT, REVERSIBLE END - FOR 3/4 IN CUTTING EDGE

2шт.

6

45 045

EDGE, CUTTING - 5/8 IN X 6 IN X 6'

-2шт.

|$12

86 333

EDGE, CUTTING - 5/8 IN X 8 IN X 6'

-2шт.

|$13

1232 966 H1

EDGE, CUTTING - 5/8 IN X 6 IN X 6' HEAT TREATED

-2шт.

|$14

161 318

EDGE, CUTTING - 3/4 IN X 6 IN X 6'

-2шт.

|$15

92 441

EDGE, CUTTING - 3/4 IN X 8 IN X 6'

-2шт.

|$16

45 046

EDGE, CUTTING - 5/8 IN X 6 IN X 7'

-2шт.

|$17

121 487

EDGE, CUTTING - 5/8 IN X 8 IN X 7'

-2шт.

|$18

1278 896 H1

EDGE, CUTTING - 5/8 IN X 6 IN X 7' HEAT TREATED

-2шт.

|$19

161 319

EDGE, CUTTING - 3/4 IN X 6 IN X 7'

-2шт.

7

45 483 A

BOLT, PLOW - DOME HEAD

-2шт.

8

25 537 R1

WASHER, FLAT

-2шт.

9

25 528 R1

NUT, HEX

-2шт.

|$26

-1шт.

|$24

F1 - NOT INCLUDED IN MOLDBOARD ASSEMBLIES,

-1шт.

|$25

MUST BE ORDERED SEPARATELY

-1шт.
