Запчасти Komatsu GD650A КОНДИЦ. ВОЗДУХА/ОБОГРЕВАТЕЛЬ. КОРПУС ASSEMBLY EVAPORATOR - заводской номер 7 И UP SUPERSTRUCTURE

|$0

1433 934 H92

BOX ASSEMBLY, AIR CONDITIONER/HEATER

1шт.

1

MOTOR ASSEMBLY (SEE PG 13-132)

-29шт.

2

1434 987 H1

FOAM, SWITCH SEAL - 15 IN

1шт.

3

1434 988 H1

FOAM, HOUSING - BOTTOM

1шт.

4

1437 225 H1

VALVE, HEATER CONTROL

1шт.

5

1434 975 H1

HOUSING, MAIN

1шт.

6

1434 536 H1

LOUVERS

4шт.

7

1434 976 H1

COVER ASSEMBLY

1шт.

8

28 144 R1

BOLT

8шт.

9

120 394

WASHER, FLAT

8шт.

10

1434 978 H91

COIL ASSEMBLY, EVAPORATOR

1шт.

|$11

1434 320 H1

COIL, EVAPORATOR

1шт.

|$12

1434 316 H1

VALVE, EXPANSION

1шт.

|$13

54 160

O-RING

1шт.

|$14

1434 308 H1

O-RING

1шт.

|$15

27 861 R1

CLAMP HOSE

1шт.

|$16

1434 979 H1

TAPE, INSULATION - 8 IN

1шт.

11

1434 980 H91

HOSE ASSEMBLY - 5/16 IN

1шт.

|$18

4199 63A A10

SWITCH, HIGH PRESSURE

1шт.

|$19

4259 63A B70

O-RING

1шт.

12

1434 981 H91

HOSE ASSEMBLY - 1/2 IN

1шт.

|$21

1432 111 H1

SWITCH, LOW PRESSURE

1шт.

|$22

4259 63A B80

0-RING

1шт.

13

1431 263 H1

PAN, DRAIN

1шт.

|$24

1431 737 H1

FITTING, BARBED

2шт.

|$25

4259 63A F10

HOSE, DRAIN - 8 IN

2шт.

|$26

4259 63A A10

VALVE, CHECK

2шт.

14

1434 312 H1

FOAM

1шт.

15

1434 982 H1

COIL, HEATER

1шт.

16

1434 983 H1

DIVIDER, AIR - R.H

1шт.

17

1434 984 H1

DIVIDER, AIR - L.H

1шт.

18

NS

BRACKET, COIL - R.H

1шт.

19

1434 986 H1

BRACKET, COIL - L.H

1шт.

20

1434 665 H1

CLAMP, HOSE

4шт.

21

1437 227 H1

HOSE, HEATER - 3 IN

1шт.

22

1437 226 H1

HOSE, HEATER - PREFORMED

1шт.

N/I

1431 225 H1

FITTING, BULKHEAD

1шт.

|$39

-1шт.

|$38

F1 - CUT FROM BULK SEAL 1434 987 H1

-1шт.
