1
PANEL, INSTRUMENT (SEE FIG. E5260-01A1)
1шт.
2
HARNESS, INSTRUMENT PANEL (SEE FIG. E5260-01A1)
1шт.
3
CONSOLE, STEERING (SEE FIG. K5410-01A4)
1шт.
4
LEVER, TURN SIGNAL AND HARNESS (SEE FIG. K5410-01A4)
1шт.
5
FLASHER, TURN SIGNAL (SEE FIG. K5410-01A4)
1шт.
6
299 412 C1
CLAMP, CABLE
2шт.
7
180 024
BOLT
2шт.
|$7
120 380
WASHER, LOCK
2шт.
8
935 522 C1
STRAP, TIE
7шт.
9
27 291 R1
CLAMP, CABLE
2шт.
10
180 022
BOLT
2шт.
|$11
120 380
WASHER, FLAT
2шт.
11
RELAY (SEE FIG. K5410-01A4)
1шт.
12
WIRING HARNESS, MAIN (SEE FIG. E5100-01A0)
1шт.
|$14
-1шт.
|$15
F1 NOT USED ON S/N 203112 AND UP
-1шт.
|$16
-1шт.
