Запчасти Komatsu GD650A-2CY FIG. A9-AA ТЕРМОСТАТ И КОЖУХ ДВИГАТЕЛЬ

1

1238 773 H1

ADAPTER, FILTER HEAD

1шт.

2

6742-01-3390

O-RING

1шт.

3

6742-01-3770

BOLT (M6-1.00x10)

1шт.

4

6736-81-8730

BOLT (M8-1.25x80)

2шт.

5

6742-01-0830

GASKET, THERMOSTAT HOUSING

1шт.

6

6731-71-4410

SHAFT, SHUTOFF VALVE

1шт.

7

6742-01-0380

HOUSING, THERMOSTAT

1шт.

8

6742-01-1900

THERMOSTAT

2шт.

9

6736-71-5860

BOLT (M8-1.25x95)

1шт.

10

6742-01-3580

GASKET, CONNECTION

1шт.

11

6742-01-3570

CONNECTION, WATER OUTLET

1шт.

12

6742-01-3980

RESISTOR, SERVICE CORROSION DCA-4(4 UNITS)

1шт.

|$12

-1шт.

|$13

F1 USE P/N 6742-01-3490 RESISTOR, CORROSION - DCA-4 (8 UNITS) FOR DRAINED SYSTEM.

-1шт.

|$14

-1шт.
