Запчасти Komatsu GD650A-2CY FIG. T-A 7/8 INCH MOLDBOARD РАБОЧЕЕ ОБОРУДОВАНИЕ

1

4609 533 H91

MOLDBOARD - 14 FT. WELDMENT

SN: 211061-211069-UP

1шт.

2

45 483 A

BOLT, PLOW - DOME HEAD

SN: 211061-211069-UP

10шт.

3

25 537 R1

WASHER, FLAT

SN: 211061-211069-UP

10шт.

4

25 528 R1

NUT, HEX

SN: 211061-211069-UP

10шт.

5

140 199

BIT, REVERSIBLE END FOR 5/8 IN. CUTTING EDGE

SN: 211061-211069-UP

2шт.

|$5

161 320

BIT, REVERSIBLE END FOR 3/4 IN. CUTTING EDGE

SN: 211061-211069-UP

2шт.

6

4609 535 H91

EDGE, CUTTING CARBIDE TIP 5 IN. X 3 FT.

SN: 211061-211069-UP

2шт.

|$7

4609 536 H91

EDGE, CUTTING CARBIDE TIP 5 IN. X 4 FT.

SN: 211061-211069-UP

2шт.

|$8

1232 966 H1

EDGE, CUTTING 5/8 IN. X 6 IN. X 6 FT. HEAT TREATED

SN: 211061-211069-UP

-2шт.

|$9

161 318

EDGE, CUTTING 3/4 IN. X 6 IN. X 6 FT.

SN: 211061-211069-UP

-2шт.

|$10

92 441

EDGE, CUTTING 3/4 IN. X 8 IN. X 6 FT.

SN: 211061-211069-UP

-2шт.

|$11

45 046

EDGE, CUTTING 5/8 IN. X 6 IN. X 7 FT.

SN: 211061-211069-UP

-2шт.

|$12

121 487

EDGE, CUTTING 5/8 IN. X 8 IN. X 7 FT.

SN: 211061-211069-UP

-2шт.

|$13

1278 896 H1

EDGE, CUTTING 5/8 IN. X 6 IN. X 7 FT. HEAT TREATED

SN: 211061-211069-UP

-1шт.

|$14

161 319

EDGE, CUTTING 3/4 IN. X 6 IN. X 7 FT.

SN: 211061-211069-UP

-2шт.

7

45 484 A

BOLT, PLOW - DOME HEAD

SN: 211061-211069-UP

32шт.

8

25 537 R1

WASHER, FLAT

SN: 211061-211069-UP

42шт.

9

25 528 R1

NUT, HEX

SN: 211061-211069-UP

42шт.

|$18

-1шт.

|$19

F1 NOT INCLUDED IN MOLDBOARD ASSEMBLIES; ORDER SEPARATELY

-1шт.

|$20

-1шт.
