Запчасти Komatsu GD650A-2CY FIG. K7-AA OPEN КАБИНА ROPS ASSEMBLY - НИЗ. PROFILE КАБИНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1435 040 H92

CAB ASSEMBLY

SN: 202642 AND UP-UP

1шт.

1

1439 477 H91

CAB WELDMENT

SN: 202642 AND UP-UP

1шт.

2

120 391

WASHER

SN: 202642 AND UP-UP

5шт.

N/I

104 696

ADHESIVE

SN: 202642 AND UP-UP

1шт.

3

120 392

WASHER

SN: 202642 AND UP-UP

13шт.

4

180 020

BOLT

SN: 202642 AND UP-UP

8шт.

5

1433 062 H1

ANGLE, UPPER SIDE - AIR RECIRC.

SN: 202642 AND UP-UP

2шт.

6

1436 675 H91

WIRING HARNESS, CAB

SN: 202642 AND UP-UP

1шт.

7

180 016

SCREW

SN: 202642 AND UP-UP

1шт.

8

MIRROR (SEE FIG. K5380-01A0)

SN: 202642 AND UP-UP

1шт.

9

149 149

SEAL

SN: 202642 AND UP-UP

1шт.

10

1259 657 H91

COVER ASSEMBLY - RIGHT

SN: 202642 AND UP-UP

1шт.

11

1259 658 H91

COVER ASSEMBLY - LEFT

SN: 202642 AND UP-UP

1шт.

12

1437 043 H1

GROMMET, RUBBER

SN: 202642 AND UP-UP

1шт.

13

1126 558 C1

CASE, OPERATOR'S MANUAL

SN: 202642 AND UP-UP

1шт.

14

1129 092 C1

CHAIN, BEAD

SN: 202642 AND UP-UP

1шт.

15

1129 094 C1

POST SCREW ASSEMBLY

SN: 202642 AND UP-UP

1шт.

16

443 874

SCREW

SN: 202642 AND UP-UP

3шт.

17

1434 776 H91

COVER, FRONT - WIPER MOTOR

SN: 202642 AND UP-UP

1шт.

18

24 539 R1

PLUG, BUTTON

SN: 202642 AND UP-UP

1шт.

19

274 957

SCREW

SN: 202642 AND UP-UP

2шт.

20

120 361

NUT

SN: 202642 AND UP-UP

2шт.

21

1262 660 H1

EDGE TRIM - 3 IN.

SN: 202642 AND UP-UP

2шт.

22

1262 660 H1

EDGE TRIM - 2.1 IN.

SN: 202642 AND UP-UP

2шт.

23

1262 660 H1

EDGE TRIM - 4.0 IN.

SN: 202642 AND UP-UP

4шт.

24

1434 778 H1

COVER

SN: 202642 AND UP-UP

1шт.

25

1435 518 H91

MOUNT, DOCUMENT

SN: 202642 AND UP-UP

1шт.

26

1433 790 H1

HOOK, COAT

SN: 202642 AND UP-UP

1шт.

|$28

23 979 R1

SCREW

SN: 202642 AND UP-UP

2шт.

27

299 415 C1

CLAMP, CLOSED

SN: 202642 AND UP-UP

2шт.

28

120 375

NUT

SN: 202642 AND UP-UP

2шт.

29

1433 929 H1

CABLE, TIE MOUNT BASE

SN: 202642 AND UP-UP

5шт.

30

935 522 C1

CABLE

SN: 202642 AND UP-UP

5шт.

31

1262 660 H1

EDGE TRIM - 140 IN.

SN: 202642 AND UP-UP

1шт.

32

1262 660 H1

EDGE TRIM - 98 IN.

SN: 202642 AND UP-UP

2шт.

33

1262 660 H1

EDGE TRIM - 153 IN.

SN: 202642 AND UP-UP

2шт.

34

1262 660 H1

EDGE TRIM - 143 IN.

SN: 202642 AND UP-UP

2шт.

35

GLASS, REAR CAB (SEE FIG. K5200-01A0)

SN: 202642 AND UP-UP

1шт.

36

SEAL, WINDOW (SEE FIG. K5200-01A0)

SN: 202642 AND UP-UP

-2шт.
