Запчасти Komatsu GD650A-2CY FIG. K7-A OPEN КАБИНА ROPS ASSEMBLY - ПОЛН. HEIGHT КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

1433 099 H92

CAB ASSEMBLY

SN: 202642 AND UP-UP

1шт.

1

1433 915 H91

CAB WELDMENT

SN: 202642 AND UP-UP

1шт.

2

1259 658 H91

COVER - L.H.

SN: 202642 AND UP-UP

1шт.

3

180 020

BOLT

SN: 202642 AND UP-UP

8шт.

4

120 392

WASHER, FLAT

SN: 202642 AND UP-UP

8шт.

5

1259 657 H91

COVER - R.H.

SN: 202642 AND UP-UP

1шт.

6

120 302

GROMMET, TOP LIGHTS

SN: 202642 AND UP-UP

2шт.

7

MIRROR (SEE FIG. K5380-01A0)

SN: 202642 AND UP-UP

1шт.

8

1434 775 H91

COVER, FRONT WIPER MOTOR

SN: 202642 AND UP-UP

1шт.

|$9

24 539 R1

PLUG, BUTTON - 1 IN.

SN: 202642 AND UP-UP

1шт.

|$10

180 016

BOLT

SN: 202642 AND UP-UP

4шт.

|$11

120 392

WASHER, FLAT

SN: 202642 AND UP-UP

4шт.

9

1252 463 H1

ANGLE, UPPER SIDE - AIR RECIRCULATION

SN: 202642 AND UP-UP

2шт.

10

TRIM, DOOR EDGE - 167 IN.

SN: 202642 AND UP-UP

2шт.

11

TRIM, BOTTOM SIDE WINDOW EDGE-95.3 IN.

SN: 202642 AND UP-UP

2шт.

12

TRIM, TOP SIDE WINDOW EDGE - 90 IN.

SN: 202642 AND UP-UP

2шт.

13

TRIM, EDGE - 2.1 IN.

SN: 202642 AND UP-UP

2шт.

14

TRIM, EDGE - 4 IN.

SN: 202642 AND UP-UP

4шт.

15

TRIM, EDGE - 3 IN.

SN: 202642 AND UP-UP

2шт.

16

TRIM, WINDOW EDGE - 158 IN.

SN: 202642 AND UP-UP

1шт.

17

TRIM, BOTTOM FRONT WINDOW EDGE-109 IN.

SN: 202642 AND UP-UP

2шт.

18

1434 778 H1

COVER

SN: 202642 AND UP-UP

1шт.

19

180 016

BOLT

SN: 202642 AND UP-UP

3шт.

|$23

120 392

WASHER, FLAT

SN: 202642 AND UP-UP

3шт.

20

149 149

SEAL - 11.91 IN.

SN: 202642 AND UP-UP

1шт.

|$25

104 696

ADHESIVE, RUBBER

SN: 202642 AND UP-UP

-2шт.

N/I

1433 790 H1

HOOK, COAT

SN: 202642 AND UP-UP

1шт.

N/I

23 979 R1

SCREW, MACHINE

SN: 202642 AND UP-UP

2шт.

N/I

1433 538 H91

WIRING HARNESS, CAB

SN: 202642 AND UP-UP

1шт.

N/I

299 415 C1

CLAMP, CABLE

SN: 202642 AND UP-UP

2шт.

N/I

120 375

NUT, HEX

SN: 202642 AND UP-UP

2шт.

21

PLATE, FLOOR (SEE FIG. K5410-01A0)

SN: 202642 AND UP-UP

1шт.

22

180 124

BOLT

SN: 202642 AND UP-UP

8шт.

|$33

25 553 R1

WASHER, FLAT

SN: 202642 AND UP-UP

8шт.

23

BOX, SEAT (SEE FIG. K5170-01A2A)

SN: 202642 AND UP-UP

1шт.

|$35

-1шт.

|$36

F1 CUT TO LENGTH FROM P/N 1262 660 H1

-1шт.

|$37

-1шт.
