Запчасти Komatsu GD650A-2CY FIG. A-AA СМАЗКА МАСЛООХЛАДИТЕЛЬ ДВИГАТЕЛЬ

1

1241 100 H1

SPRING, COMPRESSION

1шт.

2

6732-11-1920

PLUG, PIPE (3/4 NPT)

1шт.

3

6742-01-2410

PLUG, PIPE (1/2 NPT)

1шт.

4

6742-01-4540

ELEMENT, OIL FILTER

1шт.

5

6732-11-1930

PLUG, PIPE (1/8 NPT)

2шт.

6

6742-01-2440

BOLT, MOUNTING (M8-1.25x65)

11шт.

7

6742-01-1080

GASKET, OIL COOLER

1шт.

8

6742-01-2450

CORE, OIL COOLER

1шт.

9

6742-01-5202

PLUNGER, PRESSURE REGULATOR

1шт.

10

6742-01-2460

GASKET, OIL COOLER COVER

1шт.

|$10

6742-01-4220

PLUG ASSEMBLY

1шт.

11

NSS

PLUG, THREADED

1шт.

12

6742-01-5118

SEAL, O-RING

1шт.

|$13

6742-01-5041

HEAD ASSEMBLY, OIL FILTER

1шт.

13

1238 209 H1

DOWEL, RING

1шт.

14

6732-21-6610

BOLT (M8-1.25x25)

4шт.

15

6742-01-2500

HEAD, OIL FILTER

1шт.

16

6742-01-2490

GASKET, OIL FILTER

1шт.

17

NSS

COVER, OIL COOLER

1шт.

18

6731-61-2151

VALVE, PRESSURE RELIEF

1шт.

|$20

6742-01-5117

VALVE ASSEMBLY, BYPASS

1шт.

19

6742-01-2420

SEAL, O-RING

1шт.

20

NSS

VALVE, BYPASS

1шт.
