Запчасти Komatsu GD650A-2CY FIG. H8-A FOUR-WAY SWIVEL БЛОК - ВЕРХН. AND НИЖН. FEED ГИДРАВЛИКА

|$0

1439 441 H92

SWIVEL BLOCK, FOURWAY

SN: 210204 AND UP-UP

1шт.

1

59 199

CONNECTOR

SN: 210204 AND UP-UP

2шт.

|$2

364 885 R1

ORING

SN: 210204 AND UP-UP

1шт.

2

61 569

ELBOW

SN: 210204 AND UP-UP

2шт.

|$4

58 853

ORING

SN: 210204 AND UP-UP

1шт.

3

63 922

PLUG

SN: 210204 AND UP-UP

2шт.

|$6

364 839 R1

ORING

SN: 210204 AND UP-UP

1шт.

4

1439 236 H1

PIN, SWIVEL

SN: 210204 AND UP-UP

1шт.

5

1440 391 H91

BODY, SWIVEL

SN: 210204 AND UP-UP

1шт.

6

1251 923 H1

SEAL

SN: 210204 AND UP-UP

5шт.

7

1439 440 H1

COVER

SN: 210204 AND UP-UP

1шт.

8

180 175

BOLT

SN: 210204 AND UP-UP

3шт.

9

25 710 R1

WASHER

SN: 210204 AND UP-UP

3шт.

10

179 167 H1

SHIM, 0.005 THICK

SN: 210204 TO 210837-UP

3шт.

|$14

179 166 H1

SHIM, 0.007 THICK

SN: 210204 TO 210837-UP

3шт.

|$15

179 165 H1

SHIM, 0.020 THICK

SN: 210204 TO 210837-UP

2шт.

11

9410 228

CONNECTOR, STRAIGHT

SN: 210204 AND UP-UP

2шт.

|$17

364 839 R1

O-RING

SN: 210204 AND UP-UP

2шт.

12

336 192 R1

O-RING

SN: 210838 AND UP-UP

2шт.
