Запчасти Komatsu GD650A-2CY FIG. A-AA БЛОК ЦИЛИНДРОВ - SQUARED ОСНОВН. ПОДШИПНИК КРЫШКА ДВИГАТЕЛЬ

|$0

6742-01-5481

BLOCK ASSEMBLY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6742-01-1360

PLUG, EXPANSION

1шт.

3

6742-01-1370

PLUG, EXPANSION

4шт.

4

6742-01-1380

PLUG, EXPANSION

1шт.

5

6736-21-1810

PLUG, EXPANSION

1шт.

6

6742-01-5160

BUSHING

7шт.

7

6742-01-5277

CAP, MAIN BEARING

7шт.

8

6742-01-1420

PLUG, EXPANSION

4шт.

9

6742-01-1430

BOLT (M14-2.00x128)

14шт.

|$10

6742-01-5159

KIT, LINER

6шт.

10

NSS

LINER, CYLINDER

1шт.

11

6742-01-1520

SEAL, RECTANGULAR RING

1шт.

|$13

6742-01-1440

KIT, CYLINDER BLOCK HARDWARE

1шт.

|$14

6742-01-1380

PLUG, EXPANSION

2шт.

12

6216-94-3450

DRAINCOCK

1шт.

13

6735-21-5530

PLUG, EXPANSION

1шт.

14

6732-11-1910

PLUG, PIPE (1/2 NPT)

5шт.

15

6732-11-1920

PLUG, PIPE (3/4 NPT)

2шт.

16

6742-01-1460

PLUG, PIPE (1 NPT)

1шт.

17

6732-21-6120

DOWEL, PIN (M10-16)

2шт.

18

6742-01-1470

DOWEL, PIN

4шт.

19

6742-01-1480

PLUG, EXPANSION

1шт.

20

6742-01-3890

NOZZLE, PISTON COOLING

12шт.

21

6732-11-1930

PLUG, PIPE (1/8 NPT)

6шт.

|$25

1296 695 H1

SHIM, COUNTERBORE SERVICE - 0.010 IN OS

-2шт.

|$26

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 IN OS

-2шт.

|$27

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 IN OS

-2шт.

|$28

1296 698 H1

SHIM, COUNTERBORE SERVICE - 0.030 IN OS

-2шт.

|$29

1296 699 H1

SHIM, COUNTERBORE SERVICE - 0.040 IN OS

-2шт.
