Запчасти Komatsu GD650A-2 ГЕНЕРАТОР - 8 AMP ЭЛЕКТР.

|$0

1283 870 H91

ALTERNATOR ASSEMBLY - 24V, 80 AMP

1шт.

1

1285 726 H1

HOUSING ASSEMBLY, RECTIFIER

1шт.

2

470 233 C1

BEARING

1шт.

3

1213 244 H1

PLUG, BEARING WELL

1шт.

4

1213 242 H1

BUSHING, MOUNTING HINGE

1шт.

5

1213 254 H1

ROTOR ASSEMBLY

1шт.

6

1432 778 H1

STATOR ASSEMBLY

1шт.

7

NSS

CLIP, STATOR LEADS

1шт.

8

NSS

GROMMET, STATOR LEADS

1шт.

9

1213 262 H1

FRAME

1шт.

10

1218 115 H1

REGULATOR

1шт.

11

1285 727 H1

DIODE TRIO

1шт.

12

585 631 C1

BRIDGE, RECTIFIER

1шт.

13

1285 735 H1

FIELD COIL & SUPPORT

1шт.

14

470 232 C1

BEARING

1шт.

15

1213 268 H1

BEARING

1шт.

16

1432 779 H1

CAPACITOR

1шт.

|$17

1268 364 H1

BOLT, CAPACITOR

1шт.

17

1285 730 H1

TERMINAL

1шт.

18

1213 256 H1

PACKAGE RELAY

1шт.

19

1213 260 H1

BOLT, GROUND

1шт.

20

1285 725 H1

PLATE, COVER

1шт.

21

1285 728 H1

CONNECTOR, BRIDGE TO RELAY

1шт.

22

1285 729 H1

CONNECTOR, BRIDGE TO REGULATOR

1шт.

23

1285 736 H1

PLATE-RETAINER

1шт.

24

120 380 R1

WASHER, LOCK - GROUND SCREW

1шт.

25

1218 126 H1

NUT ASSY

2шт.

26

1285 738 H1

FAN

1шт.

27

1213 273 H1

NUT

1шт.

28

1285 739 H1

BOLT, BEARING RETAINER

1шт.

29

1268 363 H1

BOLT, COVER PLATE

4шт.

30

1213 252 H1

BOLT, FIELD COIL & SUPPORT

1шт.

31

1268 364 H1

BOLT, CONNECTOR TO BRIDGE

2шт.

32

1268 366 H1

BOLT, RECTIFIER BRIDGE

2шт.

33

1268 365 H1

BOLT, REGULATOR GROUND

1шт.

|$35

1268 367 H1

BOLT, REGULATOR INSULATOR

2шт.

34

1268 369 H1

WASHER

1шт.

35

1268 370 H1

WASHER

1шт.

36

1213 271 H1

BOLT

4шт.

37

1213 274 H1

CAP, RELAY TERMINAL COVER

1шт.

38

1285 737 H1

COLLAR

1шт.
