Запчасти Komatsu GD650A-2 КРЕПЛЕНИЕ ГЕНЕРАТОРА 8 AMP ЭЛЕКТР.

1

1240 142 H1

BOLT - TIGHTEN TO 16 FT/LBS WET

4шт.

2

1241 110 H1

BOLT - TIGHTEN TO 70 FT/LBS WET

1шт.

3

1241 147 H1

SUPPORT, ALTERNATOR

1шт.

4

1240 620 H1

NUT, HEX

2шт.

5

1241 108 H1

BOLT - TIGHTEN TO 70 FT/LBS WET

1шт.

6

ALTERNATOR - 80 AMP (SEE PG 08-020)

-29шт.

7

1294 330 H1

PULLEY, ALTERNATOR

1шт.

8

1213 273 H1

NUT, HEX - TIGHTEN TO 70-80 FT/LBS WET

1шт.

9

1240 087 H1

BOLT - TIGHTEN TO 70 FT/LBS WET

1шт.

10

1430 258 H1

BRACE, ALTERNATOR (REPLACES ITEM 7, PG E6-003)

1шт.

11

1240 145 H1

BOLT - TIGHTEN TO 16 FT/LBS WET

1шт.

12

1430 264 H1

BELT (REPLACES ITEM 12, PG E5-E5-009)

1шт.
