Запчасти Komatsu GD650A-2 CRANKING МОТОР ЭЛЕКТР.

|$0

1243 215 H92

MOTOR ASSEMBLY, CRANKING

1шт.

1

1223 260 H91

HOUSING ASSEMBLY, DRIVE END

1шт.

2

1211 288 H1

BUSHING, DRIVE END

1шт.

3

347 360 R1

O-RING, BETWEEN HOUSINGS

1шт.

4

1211 277 H1

PLUG, WICK

1шт.

5

NSS

WICK, OIL RESERVOIR

1шт.

6

NSS

HOUSING, DRIVE END

1шт.

|$7

21 241 R1

BOLT, MOUNTING

6шт.

7

(NOT USED)

-1шт.

8

1228 604 H1

MOTOR, DRIVE

1шт.

9

1223 258 H91

HOUSING ASSEMBLY, LEVER

1шт.

10

213 262 R1

RING, RETAINING - SHIFT LEVER SHAFT

1шт.

11

NSS

HOUSING, LEVER

1шт.

12

1211 285 H1

SEAL, OIL - LEVER HOUSING

1шт.

13

1211 286 H1

WASHER, BRAKE

1шт.

14

355 967 R1

O-RING, LEVER SHAFT (1/2 OD)

1шт.

15

352 219 R1

O-RING, LEVER SHAFT (3/8 OD)

1шт.

16

1211 152 H1

SHAFT, SHIFT LEVER

1шт.

17

NSS

LEVER, SHIFT

1шт.

18

NSS

WICK, LEVER HOUSING

1шт.

19

NSS

PLUG, WICK

1шт.

20

NSS

BUSHING, LEVER HOUSING

1шт.

21

22 411 R1

O-RING, BETWEEN HOUSINGS

1шт.

22

NSS

O-RING, BETWEEN SWITCH & LEVER HOUSING

1шт.

|$24

1245 107 H1

SCREW, LEVER HOUSING

1шт.

23

NSS

SPACER, DRIVE END

1шт.

24

1277 066 H1

CABLE, SOLENOID SWITCH TO C.E. TERMINAL

1шт.

|$27

120 217

WASHER, LOCK - AT SOLENOID SWITCH

1шт.

|$28

115 999

NUT, AT SOLENOID SWITCH

1шт.

|$29

120 396

WASHER, FLAT - AT FRAME END

1шт.

|$30

120 239

WASHER, LOCK - AT FRAME END

1шт.

|$31

1249 322 H1

NUT, AT END FRAME

1шт.

|$32

1211 267 H1

NUT & WASHER, AT END FRAME

1шт.

25

1228 450 H1

PLUNGER, SHIFT LEVER

1шт.

26

1210 070 H1

WASHER, PLUNGER

1шт.

27

1210 071 H1

BOOT, PLUNGER

1шт.

28

1210 072 H1

RETAINER, SPRING

1шт.

29

1210 073 H1

SPRING, PLUNGER

1шт.

30

1210 074 H1

RETAINER, SPRING

1шт.

31

213 262 R1

RING, RETAINING

1шт.

32

19 839 R1

NUT, LOCK - PLUNGER ROD GUIDE ADJ

1шт.

33

1228 449 H1

SWITCH, SOLENOID

1шт.

|$42

NSS

SCREW & WASHER, SWITCH MOUNTING

3шт.

34

1211 271 H1

INSULATOR, FIELD COIL - DRIVE END

1шт.

35

1211 263 H1

SHOE, POLE

4шт.

36

1211 150 H1

SCREW, POLE SHOE

8шт.

37

1228 453 H1

INSULATOR, FIELD COIL

1шт.

38

1210 061 H1

INSULATOR, INSIDE FRAME

1шт.

39

1210 062 H1

INSULATOR, OUTSIDE FRAME

1шт.

40

1228 452 H1

CONNECTOR, FIELD COIL TO SOLENOID

1шт.

|$50

1211 267 H1

NUT & WASHER, AT SOLENOID

1шт.

|$51

NSS

BOLT, MOUNTING - AT FIELD COIL

1шт.

|$52

120 385

WASHER, FLAT - AT FIELD COIL

1шт.

41

1228 454 H1

PIN, SPRING

2шт.

42

1223 256 H1

ARMATURE

1шт.

43

NSS

WASHER, THRUST

1шт.

44

1228 605 H1

COIL ASSEMBLY, FIELD

1шт.

45

NSS

PLATE, BRUSH

1шт.

|$58

1223 263 H1

SCREW & WASHER, THRU END FRAME TO PLATE

6шт.

|$59

1211 292 H1

SCREW, FIELD COIL TO PLATE

4шт.

46

NSS

BRUSH

4шт.

47

NSS

SPRING, BRUSH

4шт.

48

1223 265 H1

LEAD, TERMINAL

1шт.

49

NSS

O-RING, BETWEEN HOUSINGS

1шт.

50

1223 269 H91

PACKAGE, TERMINAL INSULATOR

1шт.

51

1223 255 H91

HOUSING ASSEMBLY, COMMUTATOR END

1шт.

52

NSS

HOUSING, END FRAME

1шт.

53

NSS

WICK, OIL RESERVOIR

1шт.

54

NSS

PLUG, WICK

1шт.

55

NSS

BUSHING, END FRAME

1шт.

56

1210 066 H1

PLUG, INSPECTION - LEVER HOUSING

1шт.

57

1211 151 H1

GASKET, INSPECTION PLUG

1шт.

|$84

-1шт.

|$73

F1 - FOR MOUNTING HARDWARE SEE PG 08-003

-1шт.

|$85

-1шт.

|$86

-1шт.

|$76

F2 - INCLUDED IN THE FOLLOWING KIT:

-1шт.

|$77

1223 266 H91

REPAIR PACKAGE, BUSHING

1шт.

|$87

-1шт.

|$79

F3 - INCLUDED IN THE FOLLOWING KIT:

-1шт.

|$80

1223 267 H91

REPAIR PACKAGE, SHIFT LEVER

1шт.

|$88

-1шт.

|$82

F4 - INCLUDED IN THE FOLLOWING KIT:

-1шт.

|$83

1223 268 H91

REPAIR PACKAGE, BRUSHES - 24 VOLT

1шт.
