Запчасти Komatsu GD650A-2 SOUND INSULATION & ПОЛ МАТЕРИАЛS SUPERSTRUCTURE

|$0

1434 188 H91

SOUND INSULATION INSTALLATION

-54шт.

1

1249 166 H91

COVER, FRONT WIPERS

1шт.

2

1252 748 H1

INSULATION, TOP FRONT

1шт.

3

1252 749 H1

INSULATION, TOP CENTER

1шт.

4

1252 750 H1

INSULATION, TOP REAR

1шт.

5

1252 751 H1

INSULATION, FRONT - R.H

1шт.

6

1252 752 H1

INSULATION, DOOR HEADER R.H

1шт.

7

1252 753 H1

INSULATION, REAR PANEL - R.H

1шт.

8

1252 756 H1

INSULATION, SIDE REAR - R.H

1шт.

9

1252 757 H1

INSULATION, SIDE REAR - L.H

1шт.

10

1252 777 H1

INSULATION, DOOR HEADER - L.H

1шт.

11

1433 776 H1

INSULATION, REAR PANEL

1шт.

12

1252 786 H1

INSULATION, FRONT - L.H

1шт.

13

1252 787 H1

INSULATION, REAR PANEL - L.H

1шт.

|$14

104 696 C1

ADHESIVE

-2шт.

14

160 515

SCREW, MACHINE

4шт.

|$16

120 392

WASHER, FLAT

4шт.

15

1253 410 H1

PLATE, DEFROSTER FAN BASE

1шт.

16

180 016

BOLT

4шт.

17

120 392

WASHER, PLAIN

4шт.

18

1259 936 H91

BRACKET, REAR COVER MOUNTING

1шт.

19

180 120

BOLT

2шт.

20

120 394

WASHER, FLAT

2шт.

21

1249 167 H91

COVER, REAR WIPER MOTOR

1шт.

|$24

1433 928 H91

FLOORMAT INSTALLATION

-54шт.

22

1433 927 H1

MAT, FLOOR - TOP

1шт.

23

1433 926 H1

MAT, FLOOR - BOTTOM

1шт.
