Запчасти Komatsu GD650A-2 SHIFT КОНСОЛЬ POWER

1

160 541

SCREW, MACHINE

14шт.

2

120 392

WASHER, FLAT

14шт.

3

1285 655 H1

DECAL - THROTTLE

1шт.

4

1433 365 H1

COVER, CONSOLE - TOP

1шт.

5

CONSOLE WELDMENT, SHIFT (SEE PG 13-026)

-29шт.

6

1433 371 H1

COVER, CONSOLE - LOWER FRONT

1шт.

7

628 588 C1

KNOB, THROTTLE LEVER

1шт.

8

25 222 R1

BOLT

4шт.

9

1433 006 H91

LEVER, THROTTLE CONTROL

1шт.

10

25 532 R1

WASHER, FLAT

3шт.

11

26 110 R1

NUT, LOCK

2шт.

12

152 864

CONTROLLER, THROTTLE

1шт.

13

1287 526 H1

ARM, THROTTLE CONTROL

1шт.

14

25 752 R1

BOLT

2шт.

|$14

26 110 R1

NUT, LOCK

2шт.

15

SHIFTER, TRANSMISSION (SEE PG 12-028)

-29шт.
