Запчасти Komatsu GD650A-2 TURBO LUBE POWER

|$0

1281 461 H92

LUBE INSTALLATION, TURBO

-54шт.

|$1

1270 003 H91

KIT, TURBO LUBE

1шт.

1

NSS

TANK, OIL ACCUMULATOR

1шт.

2

NSS

BRACKET, MOUNTING

1шт.

3

NSS

HOSE

1шт.

4

NSS

VALVE, ONE-WAY CHECK

1шт.

5

156 764 H1

CLAMP

1шт.

6

BOLT - USE EXISTING BOLT ON LUBE OIL COOLER

1шт.

7

30 175 R1

WASHER

3шт.

8

1281 698 H1

SUPPORT

1шт.

9

25 222 R1

BOLT

4шт.

10

25 532 R1

WASHER, FLAT

4шт.

11

25 519 R1

NUT, HEX

4шт.

12

1285 161 H1

HOSE

1шт.

13

444 319

REDUCER

1шт.

14

9402 864

ELBOW, STREET - 90°

1шт.

15

1281 726 H1

PLATE, TURBO-LUBE

1шт.

16

30 021 R1

BOLT

1шт.

17

30 176 R1

WASHER, FLAT

1шт.

18

86 191

BUSHING, REDUCER

1шт.

19

112 826

ADAPTOR, REDUCING

1шт.

N/I

1431 123 H1

PLUG - IN ENGINE BLOCK WHERE HOSE WAS REMOVED

1шт.

20

ELBOW (SEE PG E1-012)

-29шт.

21

HOSE (SEE PG E1-012)

-29шт.

22

TURBOCHARGER (SEE PG E1-014)

-29шт.
