Артикул
Название
Примечание
Количество
|$1
6150-71-2611
INJECTION PUMP ASS'Y
SN: 47990-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 TO A4010-G3B8.
-1шт.
|$3
ND190800-0311
GOVERNOR ASS'Y
SN: 47990-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3B8 AND A4010-E3B8.
-1шт.
1
ND190890-0130
COVER
SN: 47990-UP
1шт.
2
ND091031-0150
NUT,CAP
SN: 47990-UP
1шт.
3
ND091006-0150
SCREW,ADJUSTING
SN: 47990-UP
1шт.
4
ND090944-0310
BUSHING
SN: 47990-UP
1шт.
6
ND090991-0010
PLUG
SN: 47990-UP
2шт.
7
ND090560-0150
CAPSULE,FULL STOP
SN: 47990-UP
1шт.
8
ND090923-0060
NUT,ADAPTER LOCK
SN: 47990-UP
1шт.
9
ND090880-0120
LEVER,SWIVEL
SN: 47990-UP
1шт.
10
ND090892-0150
BUSHING
SN: 47990-UP
2шт.
12
ND949071-0090
WASHER,SNAP
SN: 47990-UP
2шт.
13
ND949047-1760
BOLT
SN: 47990-UP
4шт.
14
ND949047-1750
BOLT
SN: 47990-UP
2шт.
16
ND091071-1420
LEVER,ADJUSTING
SN: 47990-UP
1шт.
17
ND091070-1930
LEVER,ADJUSTING
SN: 47990-UP
1шт.
18
ND949047-1190
BOLT
SN: 47990-UP
1шт.
20
ND949047-1790
BOLT
SN: 47990-UP
2шт.
21
ND091051-0480
PLATE,COVER
SN: 47990-UP
1шт.
22
ND91418-06141
BOLT
SN: 47990-UP
2шт.
23
ND91418-06161
BOLT
SN: 47990-UP
2шт.
24
ND090241-0010
WASHER, 1.6MM
SN: 47990-UP
2шт.
25
ND091031-0030
NUT,CAP
SN: 47990-UP
1шт.
26
ND949062-1650
PACKING,RUBBER PLATE
SN: 47990-UP
1шт.
27
ND949130-0030
KEY
SN: 47990-UP
1шт.
29
ND949013-8210
WASHER, 0.3MM
SN: 47990-UP
-2шт.
29
ND949013-8220
WASHER, 0.6MM
SN: 47990-UP
-2шт.
29
ND949013-8230
WASHER, 0.9MM
SN: 47990-UP
-2шт.
30
ND949050-1020
NUT
SN: 47990-UP
1шт.
31
ND949018-1020
WASHER, 1.0MM
SN: 47990-UP
2шт.
33
ND091013-0050
JOINT,FORK
SN: 47990-UP
1шт.
34
ND091014-0080
PIN,STOP
SN: 47990-UP
1шт.
|$1
6150-71-2611
INJECTION PUMP ASS'Y
SN: 47990-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 TO A4010-G3B8.
-1шт.
|$3
ND190800-0311
GOVERNOR ASS'Y
SN: 47990-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3B8 AND A4010-E3B8.
-1шт.
1
ND190890-0130
COVER
SN: 47990-UP
1шт.
2
ND091031-0150
NUT,CAP
SN: 47990-UP
1шт.
3
ND091006-0150
SCREW,ADJUSTING
SN: 47990-UP
1шт.
4
ND090944-0310
BUSHING
SN: 47990-UP
1шт.
6
ND090991-0010
PLUG
SN: 47990-UP
2шт.
7
ND090560-0150
CAPSULE,FULL STOP
SN: 47990-UP
1шт.
8
ND090923-0060
NUT,ADAPTER LOCK
SN: 47990-UP
1шт.
9
ND090880-0120
LEVER,SWIVEL
SN: 47990-UP
1шт.
10
ND090892-0150
BUSHING
SN: 47990-UP
2шт.
12
ND949071-0090
WASHER,SNAP
SN: 47990-UP
2шт.
13
ND949047-1760
BOLT
SN: 47990-UP
4шт.
14
ND949047-1750
BOLT
SN: 47990-UP
2шт.
16
ND091071-1420
LEVER,ADJUSTING
SN: 47990-UP
1шт.
17
ND091070-1930
LEVER,ADJUSTING
SN: 47990-UP
1шт.
18
ND949047-1190
BOLT
SN: 47990-UP
1шт.
20
ND949047-1790
BOLT
SN: 47990-UP
2шт.
21
ND091051-0480
PLATE,COVER
SN: 47990-UP
1шт.
22
ND91418-06141
BOLT
SN: 47990-UP
2шт.
23
ND91418-06161
BOLT
SN: 47990-UP
2шт.
24
ND090241-0010
WASHER, 1.6MM
SN: 47990-UP
2шт.
25
ND091031-0030
NUT,CAP
SN: 47990-UP
1шт.
26
ND949062-1650
PACKING,RUBBER PLATE
SN: 47990-UP
1шт.
27
ND949130-0030
KEY
SN: 47990-UP
1шт.
29
ND949013-8210
WASHER, 0.3MM
SN: 47990-UP
-2шт.
29
ND949013-8220
WASHER, 0.6MM
SN: 47990-UP
-2шт.
29
ND949013-8230
WASHER, 0.9MM
SN: 47990-UP
-2шт.
30
ND949050-1020
NUT
SN: 47990-UP
1шт.
31
ND949018-1020
WASHER, 1.0MM
SN: 47990-UP
2шт.
33
ND091013-0050
JOINT,FORK
SN: 47990-UP
1шт.
34
ND091014-0080
PIN,STOP
SN: 47990-UP
1шт.
Выбрано товаров: 80
