Запчасти Komatsu 6D125-1AB-EW ТОПЛ. НАСОС (НАСОС) (/) (С МЕХАНИЧ. РЕГУЛИР.) (ВНУТР. ЧАСТИ)(№799-) ДВИГАТЕЛЬ

|$1

6150-71-2711

INJECTION PUMP ASS'Y

SN: 47990-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B7 TO A4010-G3B7.

-1шт.

|$3

ND090100-7580

BODY ASS'Y

SN: 47990-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B7 AND A4010-C3B7.

-1шт.

1

ND090131-0650

HOLDER,DELIVERY VALVE

SN: 47990-UP

6шт.

2

ND090133-0260

STOPPER,DELIVERY VALVE

SN: 47990-UP

6шт.

3

ND090136-0800

SPRING,DELIVERY

SN: 47990-UP

6шт.

4

ND090137-0100

GASKET,DELIVERY VALVE

SN: 47990-UP

6шт.

5

ND090140-1660

VALVE,DELIVERY

SN: 47990-UP

6шт.

6

ND090150-3950

ELEMENT,PUMP

SN: 47990-UP

6шт.

7

ND090156-0010

PINION,CONTROL

SN: 47990-UP

6шт.

8

ND090157-0010

SCREW,PINION

SN: 47990-UP

6шт.

9

ND090161-0330

SLEEVE,CONTROL

SN: 47990-UP

6шт.

10

ND090163-0010

SEAT,UPPER

SN: 47990-UP

6шт.

11

ND090164-0090

SPRING,PLUNGER

SN: 47990-UP

6шт.

12

ND090165-0160

SEAT,LOWER

SN: 47990-UP

6шт.

|$17

ND090170-0070

TAPPET ASS'Y

SN: 47990-UP

6шт.

13

ND090176-0050

PIN,ROLLER

SN: 47990-UP

1шт.

14

ND090169-0070

BODY,TAPPET

SN: 47990-UP

1шт.

15

ND090178-0030

BUSHING,ROLLER

SN: 47990-UP

1шт.

16

ND090181-0030

ROLLER,TAPPET

SN: 47990-UP

1шт.

17

ND949070-0111

RING,SNAP

SN: 47990-UP

1шт.

18

ND090189-0090

PLUG

SN: 47990-UP

6шт.

19

ND090212-0010

RACK,CONTROL

SN: 47990-UP

1шт.

20

ND090215-0011

SCREW,GUIDE

SN: 47990-UP

1шт.

21

ND090230-0050

PLATE,LOCK

SN: 47990-UP

3шт.

22

ND949047-2220

BOLT,WITH WASHER

SN: 47990-UP

3шт.

23

ND090311-0100

SHIM, 0.1MM

SN: 47990-UP

-2шт.

23

ND090311-0150

SHIM, 0.15MM

SN: 47990-UP

-2шт.

23

ND090311-0110

SHIM, 0.2MM

SN: 47990-UP

-2шт.

23

ND090311-0120

SHIM, 0.3MM

SN: 47990-UP

-2шт.

23

ND090311-0130

SHIM, 0.4MM

SN: 47990-UP

-2шт.

23

ND090311-0140

SHIM, 0.5MM

SN: 47990-UP

-2шт.

23

ND090311-0010

SHIM, 0.6MM

SN: 47990-UP

-2шт.

23

ND090311-0020

SHIM, 0.7MM

SN: 47990-UP

-2шт.

23

ND090311-0030

SHIM, 0.8MM

SN: 47990-UP

-2шт.

23

ND090311-0040

SHIM, 0.9MM

SN: 47990-UP

-2шт.

23

ND090311-0050

SHIM, 1.0MM

SN: 47990-UP

-2шт.

23

ND090311-0060

SHIM, 1.1MM

SN: 47990-UP

-2шт.

23

ND090311-0070

SHIM, 1.2MM

SN: 47990-UP

-2шт.

23

ND090311-0080

SHIM, 1.3MM

SN: 47990-UP

-2шт.

23

ND090311-0090

SHIM, 1.4MM

SN: 47990-UP

-2шт.

24

ND949140-2570

O-RING

SN: 47990-UP

6шт.

25

ND090018-0120

COVER,CONTROL RACK

SN: 47990-UP

1шт.
