Артикул
Название
Примечание
Количество
|$1
6150-71-2712
INJECTION PUMP ASS'Y
SN: 47990-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3C4 TO A4010-G3C4.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
ND190800-4140
GOVERNOR ASS'Y
SN: 47990-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3C4 AND A4010-E3C4.
-1шт.
1
ND091011-1670
COVER,GOVERNOR
SN: 47990-UP
1шт.
1
ND091011-2280
COVER,GOVERNOR
SN: 47990-UP
1шт.
2
ND091014-0090
PIN,STOP
SN: 47990-UP
1шт.
3
ND091024-0031
SCREW,ADJUST
SN: 47990-UP
2шт.
4
ND091031-0151
NUT
SN: 47990-UP
1шт.
5
ND091006-0150
SCREW,ADJUST
SN: 47990-UP
1шт.
6
ND090944-0310
BUSHING
SN: 47990-UP
1шт.
8
ND090991-0010
PLUG,SCREW
SN: 47990-UP
2шт.
9
ND948053-0051
NUT
SN: 47990-UP
2шт.
10
ND090560-0170
CAPSULE
SN: 47990-UP
1шт.
11
ND090923-0060
NUT
SN: 47990-UP
1шт.
15
ND949071-0090
WASHER,SNAP
SN: 47990-UP
2шт.
16
ND949047-1760
BOLT
SN: 47990-UP
4шт.
17
ND949047-1750
BOLT
SN: 47990-UP
2шт.
19
ND091071-1420
LEVER
SN: 47990-UP
1шт.
20
ND091070-4290
LEVER
SN: 47990-UP
1шт.
21
ND949047-1190
BOLT
SN: 47990-UP
1шт.
23
ND091090-1110
LEVER,STOP
SN: 47990-UP
1шт.
24
ND949047-1790
BOLT
SN: 47990-UP
2шт.
25
ND091051-0480
PLATE,COVER
SN: 47990-UP
1шт.
26
ND91418-06141
BOLT
SN: 47990-UP
3шт.
27
ND91418-06161
BOLT
SN: 47990-UP
2шт.
28
ND090241-0010
WASHER, 1.6MM
SN: 47990-UP
2шт.
29
ND091031-0030
NUT
SN: 47990-UP
1шт.
30
ND091038-0040
SPRING
SN: 47990-UP
1шт.
32
ND949140-6170
O-RING
SN: 47990-UP
1шт.
33
ND091016-0020
BUSHING,BEARING
SN: 47990-UP
1шт.
34
ND091038-0050
SPRING
SN: 47990-UP
1шт.
35
ND091035-0240
SHAFT,GOVERNOR
SN: 47990-UP
1шт.
36
ND091036-0010
CUP
SN: 47990-UP
1шт.
37
ND091034-0130
LEVER,SUPPORT
SN: 47990-UP
1шт.
38
ND091042-0030
SPRING
SN: 47990-UP
1шт.
39
ND091033-0030
PLATE
SN: 47990-UP
1шт.
40
ND091038-0030
SPRING
SN: 47990-UP
1шт.
41
ND949130-0030
KEY,WOODRUFF
SN: 47990-UP
1шт.
42
ND091043-0010
COVER
SN: 47990-UP
1шт.
43
ND090440-0440
BUSHING
SN: 47990-UP
1шт.
44
ND949013-8210
WASHER, 0.3MM
SN: 47990-UP
1шт.
44
ND949013-8220
WASHER, 0.6MM
SN: 47990-UP
1шт.
44
ND949013-8230
WASHER, 0.9MM
SN: 47990-UP
1шт.
45
ND949050-1020
NUT
SN: 47990-UP
1шт.
45
ND949050-3390
NUT
SN: 47990-UP
1шт.
46
ND949018-1020
WASHER, 1.0MM
SN: 47990-UP
2шт.
|$1
6150-71-2712
INJECTION PUMP ASS'Y
SN: 47990-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3C4 TO A4010-G3C4.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$4
ND190800-4140
GOVERNOR ASS'Y
SN: 47990-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3C4 AND A4010-E3C4.
-1шт.
1
ND091011-1670
COVER,GOVERNOR
SN: 47990-UP
1шт.
1
ND091011-2280
COVER,GOVERNOR
SN: 47990-UP
1шт.
2
ND091014-0090
PIN,STOP
SN: 47990-UP
1шт.
3
ND091024-0031
SCREW,ADJUST
SN: 47990-UP
2шт.
4
ND091031-0151
NUT
SN: 47990-UP
1шт.
5
ND091006-0150
SCREW,ADJUST
SN: 47990-UP
1шт.
6
ND090944-0310
BUSHING
SN: 47990-UP
1шт.
8
ND090991-0010
PLUG,SCREW
SN: 47990-UP
2шт.
9
ND948053-0051
NUT
SN: 47990-UP
2шт.
10
ND090560-0170
CAPSULE
SN: 47990-UP
1шт.
11
ND090923-0060
NUT
SN: 47990-UP
1шт.
15
ND949071-0090
WASHER,SNAP
SN: 47990-UP
2шт.
16
ND949047-1760
BOLT
SN: 47990-UP
4шт.
17
ND949047-1750
BOLT
SN: 47990-UP
2шт.
19
ND091071-1420
LEVER
SN: 47990-UP
1шт.
20
ND091070-4290
LEVER
SN: 47990-UP
1шт.
21
ND949047-1190
BOLT
SN: 47990-UP
1шт.
23
ND091090-1110
LEVER,STOP
SN: 47990-UP
1шт.
24
ND949047-1790
BOLT
SN: 47990-UP
2шт.
25
ND091051-0480
PLATE,COVER
SN: 47990-UP
1шт.
26
ND91418-06141
BOLT
SN: 47990-UP
3шт.
27
ND91418-06161
BOLT
SN: 47990-UP
2шт.
28
ND090241-0010
WASHER, 1.6MM
SN: 47990-UP
2шт.
29
ND091031-0030
NUT
SN: 47990-UP
1шт.
30
ND091038-0040
SPRING
SN: 47990-UP
1шт.
32
ND949140-6170
O-RING
SN: 47990-UP
1шт.
33
ND091016-0020
BUSHING,BEARING
SN: 47990-UP
1шт.
34
ND091038-0050
SPRING
SN: 47990-UP
1шт.
35
ND091035-0240
SHAFT,GOVERNOR
SN: 47990-UP
1шт.
36
ND091036-0010
CUP
SN: 47990-UP
1шт.
37
ND091034-0130
LEVER,SUPPORT
SN: 47990-UP
1шт.
38
ND091042-0030
SPRING
SN: 47990-UP
1шт.
39
ND091033-0030
PLATE
SN: 47990-UP
1шт.
40
ND091038-0030
SPRING
SN: 47990-UP
1шт.
41
ND949130-0030
KEY,WOODRUFF
SN: 47990-UP
1шт.
42
ND091043-0010
COVER
SN: 47990-UP
1шт.
43
ND090440-0440
BUSHING
SN: 47990-UP
1шт.
44
ND949013-8210
WASHER, 0.3MM
SN: 47990-UP
1шт.
44
ND949013-8220
WASHER, 0.6MM
SN: 47990-UP
1шт.
44
ND949013-8230
WASHER, 0.9MM
SN: 47990-UP
1шт.
45
ND949050-1020
NUT
SN: 47990-UP
1шт.
45
ND949050-3390
NUT
SN: 47990-UP
1шт.
46
ND949018-1020
WASHER, 1.0MM
SN: 47990-UP
2шт.
Выбрано товаров: 114
