Запчасти Komatsu 6D125-1AB-N ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (С МЕХАНИЧ. РЕГУЛИР.) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6150-71-2711

INJECTION PUMP ASS'Y

SN: 47990-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B7 TO A4010-G3B7.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND190800-1361

GOVERNOR ASS'Y

SN: 47990-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3B7 AND A4010-E3B7.

-1шт.

1

ND190890-0130

COVER,GOVERNOR

SN: 47990-UP

1шт.

2

ND091031-0150

NUT,CAP

SN: 47990-UP

1шт.

3

ND091006-0150

SCREW,ADJUST

SN: 47990-UP

1шт.

4

ND090944-0310

BUSHING

SN: 47990-UP

1шт.

5

ND090989-0010

SHAFT,LEVER SUPPORT

SN: 47990-UP

1шт.

6

ND090991-0010

PLUG

SN: 47990-UP

2шт.

7

ND090560-0170

CAPSULE,FULL STOP

SN: 47990-UP

1шт.

8

ND090923-0060

NUT,LOCK

SN: 47990-UP

1шт.

9

ND090880-0120

LEVER,SWIVEL

SN: 47990-UP

1шт.

10

ND090892-0150

BUSHING,LEVER

SN: 47990-UP

2шт.

11

ND949140-5760

O-RING

SN: 47990-UP

2шт.

12

ND949071-0090

WASHER,SNAP

SN: 47990-UP

2шт.

13

ND949047-1760

BOLT

SN: 47990-UP

4шт.

14

ND949047-1750

BOLT

SN: 47990-UP

2шт.

15

ND949150-2690

SEAL,OIL

SN: 47990-UP

1шт.

16

ND091071-1420

LEVER,ADJUST

SN: 47990-UP

1шт.

17

ND091070-1930

LEVER,ADJUST

SN: 47990-UP

1шт.

18

ND949047-1190

BOLT

SN: 47990-UP

1шт.

19

ND091094-0060

CAP

SN: 47990-UP

1шт.

20

ND949047-1790

BOLT

SN: 47990-UP

2шт.

21

ND091051-0480

PLATE,COVER

SN: 47990-UP

1шт.

22

ND91418-06141

BOLT

SN: 47990-UP

2шт.

23

ND91418-06161

BOLT

SN: 47990-UP

2шт.

24

ND090241-0010

WASHER, 1.6MM

SN: 47990-UP

2шт.

25

ND091031-0030

NUT,CAP

SN: 47990-UP

1шт.

26

ND949062-1650

PACKING,RUBBER

SN: 47990-UP

1шт.

27

ND949130-0030

KEY

SN: 47990-UP

1шт.

28

ND090944-0440

BUSHING

SN: 47990-UP

1шт.

29

ND949013-8210

WASHER, 0.3MM

SN: 47990-UP

-2шт.

29

ND949013-8220

WASHER, 0.6MM

SN: 47990-UP

-2шт.

29

ND949013-8230

WASHER, 0.9MM

SN: 47990-UP

-2шт.

30

ND949050-1020

NUT

SN: 47990-UP

1шт.

31

ND949018-1020

WASHER, 1.0MM

SN: 47990-UP

2шт.

32

ND049140-5740

O-RING

SN: 47990-UP

1шт.
