Запчасти Komatsu 6D125-1AB-N ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (СПЕЦ-Я ДЛЯ БОЛЬШИХ ВЫСОТ.) (С МЕХАНИЧ. РЕГУЛИР.) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6150-71-2611

INJECTION PUMP ASS'Y

SN: 47990-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 TO A4010-G3B8.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND190800-0311

GOVERNOR ASS'Y

SN: 47990-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3B8 AND A4010-E3B8.

-1шт.

1

ND090810-0390

HOUSING

SN: 47990-UP

1шт.

2

ND090878-0040

PLATE

SN: 47990-UP

1шт.

3

ND091024-0031

SCREW,ADJUSTING

SN: 47990-UP

2шт.

4

ND090901-0200

LEVER ASS'Y,TENSION

SN: 47990-UP

1шт.

5

ND090930-0490

LEVER ASS'Y,CONTROL

SN: 47990-UP

1шт.

6

ND090894-0010

E-RING

SN: 47990-UP

1шт.

7

ND948053-0051

NUT

SN: 47990-UP

2шт.

8

ND091046-0010

SLIDER

SN: 47990-UP

1шт.

9

ND090970-0350

SHACKLE ASS'Y

SN: 47990-UP

1шт.

10

ND949130-0050

KEY

SN: 47990-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 47990-UP

1шт.

12

ND949015-0500

WASHER, 2.5MM,SPRING

SN: 47990-UP

1шт.

13

ND090844-0010

NUT

SN: 47990-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y,GOVERNOR

SN: 47990-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 47990-UP

1шт.

16

ND90567-30000

RING

SN: 47990-UP

1шт.

17

ND949013-4090

WASHER, 0.1MM

SN: 47990-UP

-2шт.

17

ND949013-4060

WASHER, 0.2MM

SN: 47990-UP

-2шт.

17

ND949013-4070

WASHER, 0.3MM

SN: 47990-UP

-2шт.

17

ND949013-4080

WASHER, 0.4MM

SN: 47990-UP

-2шт.

17

ND949013-4100

WASHER, 1.0MM

SN: 47990-UP

-2шт.

18

ND090992-0480

SPRING,CONTROL

SN: 47990-UP

1шт.

|$28

ND090910-1760

ADAPTER ASS'Y

SN: 47990-UP

1шт.

19

ND090911-0020

SCREW,ADAPTER

SN: 47990-UP

1шт.

20

ND090919-0341

ADAPTER

SN: 47990-UP

1шт.

21

ND090918-0110

SPRING,GOVERNOR

SN: 47990-UP

1шт.

22

ND090918-2081

SPRING,GOVERNOR

SN: 47990-UP

1шт.

23

ND949013-3890

WASHER, 0.1MM

SN: 47990-UP

-2шт.

23

ND949013-4110

WASHER, 0.2MM

SN: 47990-UP

-2шт.

24

ND949013-4450

WASHER, 0.1MM

SN: 47990-UP

-2шт.

24

ND949013-3750

WASHER, 0.3MM

SN: 47990-UP

-2шт.

25

ND090923-0011

NUT

SN: 47990-UP

1шт.

26

ND090224-0140

PLUG

SN: 47990-UP

1шт.

27

ND090119-0040

GASKET,PUMP BODY

SN: 47990-UP

1шт.

28

ND090823-0230

GASKET

SN: 47990-UP

1шт.

29

ND090993-0280

SPRING,START

SN: 47990-UP

1шт.

30

ND090245-0230

SCREW

SN: 47990-UP

1шт.

31

ND090222-0120

WASHER

SN: 47990-UP

2шт.

32

ND949047-0620

BOLT

SN: 47990-UP

2шт.

33

ND91418-06201

BOLT

SN: 47990-UP

2шт.

34

ND91518-06161

BOLT

SN: 47990-UP

4шт.
