Запчасти Komatsu 6D125-1AB-N ТОПЛ. НАСОС (НАСОС) (/) (СПЕЦ-Я ДЛЯ БОЛЬШИХ ВЫСОТ.) (С МЕХАНИЧ. РЕГУЛИР.) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6150-71-2611

INJECTION PUMP ASS'Y

SN: 47990-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 TO A4010-G3B8.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND090100-6710

BODY ASS'Y

SN: 47990-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B8 AND A4010-C3B8.

-1шт.

1

ND090130-0290

HOLDER,DELIVERY VALVE

SN: 47990-UP

6шт.

2

ND090136-0770

SPRING,DELIVERY

SN: 47990-UP

6шт.

3

ND949140-2570

O-RING

SN: 47990-UP

6шт.

4

ND090140-1430

VALVE SUB ASS'Y,DELIVERY

SN: 47990-UP

6шт.

5

ND090150-3250

ELEMENT,PUMP

SN: 47990-UP

6шт.

6

ND090160-0060

SLEEVE,CONTROL

SN: 47990-UP

6шт.

7

ND090212-0471

RACK,CONTROL

SN: 47990-UP

1шт.

8

ND090163-0131

SEAT,UPPER

SN: 47990-UP

6шт.

9

ND090164-0250

SPRING,PLUNGER

SN: 47990-UP

6шт.

10

ND090165-0150

SEAT,LOWER

SN: 47990-UP

6шт.

11

ND090170-0230

TAPPET ASS'Y

SN: 47990-UP

6шт.

12

ND090438-0390

SHIM, 1.75MM

SN: 47990-UP

-2шт.

12

ND090438-0400

SHIM, 1.8MM

SN: 47990-UP

-2шт.

12

ND090438-0410

SHIM, 1.85MM

SN: 47990-UP

-2шт.

12

ND090438-0420

SHIM, 1.9MM

SN: 47990-UP

-2шт.

12

ND090438-0430

SHIM, 1.95MM

SN: 47990-UP

-2шт.

12

ND090438-0440

SHIM, 2.0MM

SN: 47990-UP

-2шт.

12

ND090438-0450

SHIM, 2.05MM

SN: 47990-UP

-2шт.

12

ND090438-0460

SHIM, 2.1MM

SN: 47990-UP

-2шт.

12

ND090438-0470

SHIM, 2.15MM

SN: 47990-UP

-2шт.

12

ND090438-0480

SHIM, 2.2MM

SN: 47990-UP

-2шт.

12

ND090438-0490

SHIM, 2.25MM

SN: 47990-UP

-2шт.

12

ND090438-0500

SHIM, 2.3MM

SN: 47990-UP

-2шт.

12

ND090438-0510

SHIM, 2.35MM

SN: 47990-UP

-2шт.

12

ND090438-0520

SHIM, 2.4MM

SN: 47990-UP

-2шт.

13

ND949013-5880

WASHER

SN: 47990-UP

12шт.

14

ND090139-0020

O-RING

SN: 47990-UP

18шт.

15

ND949018-1730

WASHER

SN: 47990-UP

6шт.

16

ND090215-0011

SCREW,GUIDE

SN: 47990-UP

1шт.

17

ND090114-0110

BUSHING,CONTROL

SN: 47990-UP

2шт.

18

ND090367-0040

BUSHING,CONTROL

SN: 47990-UP

1шт.

19

ND090018-0410

COVER,CONTROL RACK

SN: 47990-UP

1шт.

20

ND949018-1550

WASHER

SN: 47990-UP

1шт.
