Запчасти Komatsu 6D125-1AB-N ТОПЛ. НАСОС (НАСОС) (/) (С МЕХАНИЧ. РЕГУЛИР.) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6150-71-2711

INJECTION PUMP ASS'Y

SN: 47990-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B7 TO A4010-G3B7.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND090100-7580

BODY ASS'Y

SN: 47990-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3B7 AND A4010-C3B7.

-1шт.

1

ND190110-4110

HOUSING,PUMP

SN: 47990-UP

1шт.

2

ND949043-0010

STUD

SN: 47990-UP

3шт.

3

ND090191-1180

CAMSHAFT

SN: 47990-UP

1шт.

4

ND090193-0020

RING,ADJUST

SN: 47990-UP

1шт.

5

ND090194-0010

SHIM, 0.10MM

SN: 47990-UP

-2шт.

5

ND090194-0020

SHIM, 0.12MM

SN: 47990-UP

-2шт.

5

ND090194-0030

SHIM, 0.14MM

SN: 47990-UP

-2шт.

5

ND090194-0040

SHIM, 0.16MM

SN: 47990-UP

-2шт.

5

ND090194-0050

SHIM, 0.18MM

SN: 47990-UP

-2шт.

5

ND090194-0110

SHIM, 0.3MM

SN: 47990-UP

-2шт.

5

ND090194-0060

SHIM, 0.50MM

SN: 47990-UP

-2шт.

5

ND090194-0140

SHIM, 1.0MM

SN: 47990-UP

-2шт.

5

ND090194-0150

SHIM, 1.5MM

SN: 47990-UP

-2шт.

6

ND090201-0310

COVER,BEARING

SN: 47990-UP

1шт.

7

ND949140-1550

O-RING

SN: 47990-UP

1шт.

8

ND949150-1620

SEAL,OIL

SN: 47990-UP

1шт.

|$22

ND090270-0691

COVER ASS'Y,PUMP

SN: 47990-UP

1шт.

9

ND090275-0083

COVER

SN: 47990-UP

1шт.

10

ND090272-0220

GASKET,PLATE

SN: 47990-UP

1шт.

11

ND090243-0030

WASHER

SN: 47990-UP

2шт.

12

ND090276-0030

SCREW

SN: 47990-UP

2шт.

13

ND949047-1360

BOLT,WITH WASHER

SN: 47990-UP

4шт.

14

ND949101-0120

BEARING,ROLLER

SN: 47990-UP

1шт.

15

ND949140-0380

O-RING

SN: 47990-UP

1шт.

16

ND090310-0080

VALVE ASS'Y,OVER FLOW

SN: 47990-UP

1шт.

17

ND090361-0040

BEARING,CENTER

SN: 47990-UP

1шт.

18

ND91050-05351

SCREW

SN: 47990-UP

2шт.

19

ND949018-1030

WASHER

SN: 47990-UP

2шт.

20

ND949180-0310

SCREW

SN: 47990-UP

2шт.

21

ND090222-0070

WASHER

SN: 47990-UP

6шт.

22

ND090193-0050

RING,ADJUST

SN: 47990-UP

1шт.

23

ND090194-0070

PLATE, 0.1MM

SN: 47990-UP

-2шт.

23

ND090194-0340

PLATE, 0.12MM

SN: 47990-UP

-2шт.

23

ND090194-0350

PLATE, 0.14MM

SN: 47990-UP

-2шт.

23

ND090194-0080

PLATE, 0.15MM

SN: 47990-UP

-2шт.

23

ND090194-0360

PLATE, 0.18MM

SN: 47990-UP

-2шт.

23

ND090194-0090

PLATE, 0.3MM

SN: 47990-UP

-2шт.

23

ND090194-0100

PLATE, 0.5MM

SN: 47990-UP

-2шт.

24

ND949101-0071

BEARING,ROLLER

SN: 47990-UP

1шт.

25

ND090012-0180

NUT,ROUND

SN: 47990-UP

1шт.

26

ND90258-08001

WASHER,SPRING

SN: 47990-UP

1шт.

27

ND949130-0210

KEY

SN: 47990-UP

1шт.
