Запчасти Komatsu GD611A-1 СИСТЕМА ROPS РАМА И ЧАСТИ КОРПУСА

Схема запчастей Komatsu GD611A-1 - СИСТЕМА ROPS РАМА И ЧАСТИ КОРПУСА
1
2
3
4
5

Артикул

Название

Примечание

Количество

1

23B-957-1110

ROPS CANOPY,(FULL)

SN: 10001-UP

1шт.

1

23B-957-1210

ROPS CANOPY,(LOW)

SN: 10001-UP

1шт.

2

01010-52485

BOLT

SN: 10001-UP

8шт.

3

01643-32460

WASHER

SN: 10001-UP

8шт.

4

09620-30200

PLATE, NAME,(LIMITED SUPPLY) (ENGLISH)

SN: 10001-UP

1шт.

4

09620-02200

PLATE, NAME,(LIMITED SUPPLY) (ARABIC)

SN: 10001-UP

1шт.

4

09620-60200

PLATE, NAME,(LIMITED SUPPLY) (ITALIAN)

SN: 10001-UP

1шт.

4

09620-05200

PLATE, NAME,(LIMITED SUPPLY) (INDONESIAN)

SN: 10001-UP

1шт.

4

09620-80200

PLATE, NAME,(LIMITED SUPPLY) (GREEK)

SN: 10001-UP

1шт.

4

09620-10200

PLATE, NAME,(LIMITED SUPPLY) (SPANISH)

SN: 10001-UP

1шт.

4

09620-03200

PLATE, NAME,(LIMITED SUPPLY) (CZECH.)

SN: 10001-UP

1шт.

4

09620-90200

PLATE, NAME,(LIMITED SUPPLY) (CHINESE)

SN: 10001-UP

1шт.

4

09620-20200

PLATE, NAME,(LIMITED SUPPLY) (GERMAN)

SN: 10001-UP

1шт.

4

09620-50200

PLATE, NAME,(LIMITED SUPPLY) (FRENCH)

SN: 10001-UP

1шт.

4

09620-04200

PLATE, NAME,(LIMITED SUPPLY) (PERSIAN)

SN: 10001-UP

1шт.

4

09620-70200

PLATE, NAME,(LIMITED SUPPLY) (PORTUGUESE)

SN: 10001-UP

1шт.

4

09620-40200

PLATE, NAME,(LIMITED SUPPLY) (RUSSIAN)

SN: 10001-UP

1шт.

4

09620-06200

PLATE, NAME,(LIMITED SUPPLY) (POLISH)

SN: 10001-UP

1шт.

5

04418-13060

SCREW

SN: 10001-UP

4шт.

Выбрано товаров: 19
