Запчасти Komatsu GD555-3A КАБИНА (КРЫШКА И ПЛАСТИНА) (ВЫС. КАБИНА ROPS) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$24

23B-953-4090

CAB ASS'Y

SN: 11001-UP

1шт.

|$25

23B-953-1011

CAB ASS'Y

SN: 10001-11000

1шт.

|$26

23B-953-5010

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 11001-UP

1шт.

|$27

23B-953-1021

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 10001-11000

1шт.

|$28

23B-953-5020

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 11001-UP

1шт.

|$29

23B-953-1031

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 10001-11000

1шт.

|$30

23B-953-5030

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 11001-UP

1шт.

|$31

23B-953-1041

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 10001-11000

1шт.

|$32

23B-953-5040

CAB ASS'Y

SN: 11001-UP

1шт.

|$33

23B-953-5050

CAB ASS'Y

SN: 11001-UP

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-16B0.

-1шт.

|$35

23B-953-5060

CAB ASS'Y,(W/A.C.)

SN: 11001-UP

1шт.

|$36

23B-953-1072

CAB ASS'Y,(W/A.C.)

SN: 10001-11000

1шт.

|$37

23B-953-6030

CAB ASS'Y,(WITH HEATER)

SN: 11001-UP

1шт.

|$38

23B-953-3030

CAB ASS'Y,(WITH HEATER)

SN: 10001-11000

1шт.

|$39

23B-953-5070

CAB ASS'Y

SN: 11001-UP

1шт.

|$40

23B-953-5080

CAB ASS'Y

SN: 11001-UP

1шт.

|$41

23B-953-5090

CAB ASS'Y

SN: 11001-UP

1шт.

|$42

23B-953-6010

CAB ASS'Y

SN: 11001-UP

1шт.

|$43

23B-953-6020

CAB ASS'Y

SN: 11001-UP

1шт.

|$44

23B-953-6040

CAB ASS'Y

SN: 11001-UP

1шт.

|$45

23B-953-6050

CAB ASS'Y

SN: 11001-UP

1шт.

|$46

23B-953-6060

CAB ASS'Y

SN: 11001-UP

1шт.

|$47

23B-953-6070

CAB ASS'Y

SN: 11001-UP

1шт.

|$48

23B-953-6080

CAB ASS'Y

SN: 11001-UP

1шт.

|$$26

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-17B4.

-1шт.

1

09970-00230

PLATE,MARK, GALEO

SN: 10001-11000

2шт.

2

09415-01008

CAP,(FOR FAN LESS)

SN: 10001-UP

1шт.

3

23B-952-2360

CAP

SN: 10001-UP

2шт.

4

09415-02520

CAP,(FOR FAN LESS)

SN: 10001-UP

1шт.

5

01023-70410

SCREW

SN: 11164-UP

2шт.

6

09415-00506

CAP

SN: 11164-UP

2шт.

7

09415-01610

CAP

SN: 10001-UP

1шт.

8

01010-D1016

BOLT

SN: 11164-UP

4шт.

9

01643-71032

WASHER

SN: 11164-UP

4шт.

10

23B-952-2360

CAP

SN: 10001-UP

1шт.

11

421-54-22990

PLUG

SN: 11029-UP

8шт.

12

09415-01008

CAP

SN: 11029-UP

1шт.
