Запчасти Komatsu GD555-3A КАБИНА (КАБИНА Э/ПРОВОДКА) (НИЗ. КАБИНА ROPS) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$24

23B-952-4090

CAB ASS'Y

SN: 11001-UP

1шт.

|$25

23B-952-1011

CAB ASS'Y

SN: 10001-11000

1шт.

|$26

23B-952-5010

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 11001-UP

1шт.

|$27

23B-952-1021

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 10001-11000

1шт.

|$28

23B-952-5020

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 11001-UP

1шт.

|$29

23B-952-1031

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 10001-11000

1шт.

|$30

23B-952-5030

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 11001-UP

1шт.

|$31

23B-952-1041

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 10001-11000

1шт.

|$32

23B-952-5040

CAB ASS'Y

SN: 11001-UP

1шт.

|$33

23B-952-7040

CAB ASS'Y

SN: 11001-UP

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-16A0

-1шт.

|$35

23B-952-5060

CAB ASS'Y,(W/A.C.)

SN: 11001-UP

1шт.

|$36

23B-952-1072

CAB ASS'Y,(W/A.C.)

SN: 10001-11000

1шт.

|$37

23B-952-6030

CAB ASS'Y,(WITH HEATER)

SN: 11001-UP

1шт.

|$38

23B-952-3030

CAB ASS'Y,(WITH HEATER)

SN: 10001-11000

1шт.

|$39

23B-952-5070

CAB ASS'Y

SN: 11001-UP

1шт.

|$40

23B-952-5080

CAB ASS'Y

SN: 11001-UP

1шт.

|$41

23B-952-5090

CAB ASS'Y

SN: 11001-UP

1шт.

|$42

23B-952-6010

CAB ASS'Y

SN: 11001-UP

1шт.

|$43

23B-952-6020

CAB ASS'Y

SN: 11001-UP

1шт.

|$44

23B-952-6040

CAB ASS'Y

SN: 11001-UP

1шт.

|$45

23B-952-6050

CAB ASS'Y

SN: 11001-UP

1шт.

|$46

23B-952-6060

CAB ASS'Y

SN: 11001-UP

1шт.

|$47

23B-952-6070

CAB ASS'Y

SN: 11001-UP

1шт.

|$48

23B-952-6080

CAB ASS'Y

SN: 11001-UP

1шт.

|$$26

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A4

-1шт.

1

0

CAB

SN: 11001-UP

1шт.

1

0

CAB

SN: 10001-11000

1шт.

2

23A-952-1562

WIRING HARNESS

SN: 11029-UP

1шт.

2

23A-952-1561

WIRING HARNESS

SN: 10001-11028

1шт.

3

01010-D0810

BOLT

SN: 11001-UP

2шт.

3

01010-D0810

BOLT

SN: 10001-11000

1шт.

4

01643-70823

WASHER

SN: 10001-UP

2шт.

5

20Y-54-11611

STOPPER

SN: 11022-UP

2шт.

5

23A-952-1430

STOPPER

SN: 10001-11021

2шт.

6

01580-11008

NUT

SN: 10001-UP

2шт.

7

23B-952-2360

CAP

SN: 10001-UP

3шт.

8

421-56-21720

CAP

SN: 10001-UP

4шт.
