Запчасти Komatsu GD555-3A КАБИНА (КАБИНА EXTERIOR ЧАСТИ) (ВЫС. КАБИНА ROPS) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$26

23B-953-4090

CAB ASS'Y

SN: 11001-UP

1шт.

|$27

23B-953-1011

CAB ASS'Y

SN: 10001-11000

1шт.

|$28

23B-953-5010

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 11001-UP

1шт.

|$29

23B-953-1021

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 10001-11000

1шт.

|$30

23B-953-5020

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 11001-UP

1шт.

|$31

23B-953-1031

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 10001-11000

1шт.

|$32

23B-953-5030

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 11001-UP

1шт.

|$33

23B-953-1041

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 10001-11000

1шт.

|$34

23B-953-5040

CAB ASS'Y

SN: 11001-UP

1шт.

|$35

23B-953-5050

CAB ASS'Y

SN: 11001-UP

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-16B0.

-1шт.

|$37

23B-953-5060

CAB ASS'Y,(W/A.C.)

SN: 11001-UP

1шт.

|$38

23B-953-1072

CAB ASS'Y,(W/A.C.)

SN: 10001-11000

1шт.

|$39

23B-953-6030

CAB ASS'Y,(WITH HEATER)

SN: 11001-UP

1шт.

|$40

23B-953-3030

CAB ASS'Y,(WITH HEATER)

SN: 10001-11000

1шт.

|$41

23B-953-5070

CAB ASS'Y

SN: 11001-UP

1шт.

|$42

23B-953-5080

CAB ASS'Y

SN: 11001-UP

1шт.

|$43

23B-953-5090

CAB ASS'Y

SN: 11001-UP

1шт.

|$44

23B-953-6010

CAB ASS'Y

SN: 11001-UP

1шт.

|$45

23B-953-6020

CAB ASS'Y

SN: 11001-UP

1шт.

|$46

23B-953-6040

CAB ASS'Y

SN: 11001-UP

1шт.

|$47

23B-953-6050

CAB ASS'Y

SN: 11001-UP

1шт.

|$48

23B-953-6060

CAB ASS'Y

SN: 11001-UP

1шт.

|$49

23B-953-6070

CAB ASS'Y

SN: 11001-UP

1шт.

|$50

23B-953-6080

CAB ASS'Y

SN: 11001-UP

1шт.

|$$26

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-17B4.

-1шт.

|$52

23B-953-3620

CAB ASS'Y

SN: 11001-UP

1шт.

|$53

23B-953-3720

CAB ASS'Y

SN: 11001-UP

1шт.

|$$29

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-19H1.

-1шт.

1

23A-953-1390

TRIM

SN: 10001-UP

2шт.

2

23A-952-1410

TRIM

SN: 10001-UP

2шт.

3

23A-952-1420

SEAL

SN: 10001-UP

1шт.

4

20Y-54-11611

STOPPER

SN: 10001-UP

4шт.

5

20T-54-74550

NUT

SN: 10001-UP

4шт.

6

23A-952-1440

BRACKET,L.H.

SN: 10001-UP

1шт.

7

23A-952-1450

BRACKET,R.H.

SN: 10001-UP

1шт.

8

01010-D0816

BOLT

SN: 10001-UP

4шт.

9

01643-70823

WASHER

SN: 10001-UP

4шт.

10

23B-953-1130

WIPER MOTOR ASS'Y

SN: 10001-UP

1шт.

11

01435-00616

BOLT

SN: 10001-UP

4шт.

12

418-923-1270

ARM,WIPER

SN: 10001-UP

1шт.

13

195-Z11-8550

BLADE,WIPER

SN: 10001-UP

1шт.

14

22T-55-11630

NOZZLE ASS'Y

SN: 10001-UP

1шт.

15

23A-953-1520

HOSE, 5500MM

SN: 10001-UP

1шт.

16

23A-952-1550

HOSE, 2000MM

SN: 10001-UP

1шт.

17

120-Y79-5760

VALVE

SN: 10001-UP

1шт.

18

21J-54-16190

STRIKER

SN: 10001-UP

2шт.

19

01240-01020

SCREW

SN: 10001-UP

4шт.

20

20U-54-25190

WASHER

SN: 10001-UP

4шт.

21

23A-952-1890

PLATE

SN: 10001-UP

2шт.

22

23B-952-1871

HANDRAIL,L.H.

SN: 10001-UP

1шт.

23

23B-952-2250

HANDRAIL,R.H.

SN: 10001-UP

1шт.

24

01435-40820

BOLT

SN: 10001-UP

8шт.
