Запчасти Komatsu GD555-3A КАБИНА (КАБИНА EXTERIOR ЧАСТИ) (НИЗ. КАБИНА ROPS) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$25

23B-952-4090

CAB ASS'Y

SN: 11001-UP

1шт.

|$26

23B-952-1011

CAB ASS'Y

SN: 10001-11000

1шт.

|$27

23B-952-5010

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 11001-UP

1шт.

|$28

23B-952-1021

CAB ASS'Y,(W/FRONT L. AND REAR WIPER)

SN: 10001-11000

1шт.

|$29

23B-952-5020

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 11001-UP

1шт.

|$30

23B-952-1031

CAB ASS'Y,(W/RADIO F/SOUTH AMERICA)

SN: 10001-11000

1шт.

|$31

23B-952-5030

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 11001-UP

1шт.

|$32

23B-952-1041

CAB ASS'Y,(W/RADIO F/ASIA)

SN: 10001-11000

1шт.

|$33

23B-952-5040

CAB ASS'Y

SN: 11001-UP

1шт.

|$34

23B-952-7040

CAB ASS'Y

SN: 11001-UP

1шт.

|$$11

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-16A0

-1шт.

|$36

23B-952-5060

CAB ASS'Y,(W/A.C.)

SN: 11001-UP

1шт.

|$37

23B-952-1072

CAB ASS'Y,(W/A.C.)

SN: 10001-11000

1шт.

|$38

23B-952-6030

CAB ASS'Y,(WITH HEATER)

SN: 11001-UP

1шт.

|$39

23B-952-3030

CAB ASS'Y,(WITH HEATER)

SN: 10001-11000

1шт.

|$40

23B-952-5070

CAB ASS'Y

SN: 11001-UP

1шт.

|$41

23B-952-5080

CAB ASS'Y

SN: 11001-UP

1шт.

|$42

23B-952-5090

CAB ASS'Y

SN: 11001-UP

1шт.

|$43

23B-952-6010

CAB ASS'Y

SN: 11001-UP

1шт.

|$44

23B-952-6020

CAB ASS'Y

SN: 11001-UP

1шт.

|$45

23B-952-6040

CAB ASS'Y

SN: 11001-UP

1шт.

|$46

23B-952-6050

CAB ASS'Y

SN: 11001-UP

1шт.

|$47

23B-952-6060

CAB ASS'Y

SN: 11001-UP

1шт.

|$48

23B-952-6070

CAB ASS'Y

SN: 11001-UP

1шт.

|$49

23B-952-6080

CAB ASS'Y

SN: 11001-UP

1шт.

|$$26

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A4

-1шт.

|$51

23B-952-3650

CAB ASS'Y

SN: 11001-UP

1шт.

|$$28

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-19E2.

-1шт.

1

23A-952-1391

TRIM

SN: 10001-UP

2шт.

2

23A-952-1410

TRIM

SN: 10001-UP

2шт.

3

23A-952-1420

SEAL

SN: 10001-UP

1шт.

4

20Y-54-11611

STOPPER

SN: 10001-UP

4шт.

5

20T-54-74550

NUT

SN: 10001-UP

4шт.

6

23A-952-1440

BRACKET,L.H.

SN: 10001-UP

1шт.

7

23A-952-1450

BRACKET,R.H.

SN: 10001-UP

1шт.

8

01010-D0816

BOLT

SN: 10001-UP

4шт.

9

01643-70823

WASHER

SN: 10001-UP

4шт.

10

08180-12411

WIPER MOTOR ASS'Y

SN: 10001-UP

1шт.

11

01023-60512

SCREW

SN: 10001-UP

2шт.

12

20T-54-84840

ARM,WIPER

SN: 10001-UP

1шт.

13

20T-54-74990

BLADE,WIPER

SN: 10001-UP

1шт.

14

22T-55-11630

NOZZLE ASS'Y

SN: 10001-UP

1шт.

15

23A-952-1521

HOSE, 5200MM

SN: 10001-UP

1шт.

16

23A-952-1550

HOSE, 2000MM

SN: 10001-UP

1шт.

17

120-Y79-5760

VALVE

SN: 10001-UP

1шт.

18

21J-54-16190

STRIKER

SN: 10001-UP

2шт.

19

01240-01020

SCREW

SN: 10001-UP

4шт.

20

20U-54-25190

WASHER

SN: 10001-UP

4шт.

21

23A-952-1890

PLATE

SN: 10001-UP

2шт.

22

23B-952-1871

HANDRAIL,L.H.

SN: 10001-UP

1шт.

23

23B-952-2250

HANDRAIL,R.H.

SN: 10001-UP

1шт.

24

01435-40820

BOLT

SN: 10001-UP

8шт.
