Запчасти Komatsu GD530A SENDING БЛОКS ЭЛЕКТР.

1

1438 367 H1

SWITCH, BRAKE PRESSURE

1шт.

|$1

364 839 R1

O-RING

1шт.

2

1430 227 H2

SWITCH, HIGH PRESSURE

1шт.

|$3

364 839 R1

O-RING

1шт.

3

1282 169 H1

SWITCH, HYDRAULIC OIL TEMPERATURE

a

1шт.

|$5

158 982

SWITCH, HYDRAULIC OIL TEMPERATURE

b

1шт.

4

ELBOW, SPECIAL - 90° (SEE PG 06-002)

-29шт.

5

1432 879 H1

SENDING UNIT, CONVERTER OIL TEMPERATURE

1шт.

6

1137 360 C2

SWITCH, ENGINE WATER TEMPERATURE

1шт.

7

1216 162 H1

SENDING UNIT, ENGINE WATER TEMPERATURE

1шт.

8

677 161 R94

SENDING UNIT, ENGINE OIL PRESSURE

1шт.

9

1436 569 H1

SWITCH, ENGINE OIL PRESSURE

1шт.

10

1431 126 H1

SCREW, SELF-TAPPING

5шт.

11

55 845 C

SENDING UNIT, FUEL GAUGE

1шт.

12

29 362

GASKET

1шт.

13

1436 571 H1

SWITCH, CLUTCH PRESSURE

1шт.

14

161 849

COUPLING, QUICK DISCONNECT

1шт.

15

162 144

CAP, DUST

1шт.

16

9409 943

TEE

1шт.

17

1438 446 H1

ADAPTER

1шт.

18

TRANSMISSION (SEE PG 07-006)

-29шт.

|$21

1430 839 H91

KIT, SPEEDOMETER SENSOR

1шт.

19

20 900

O-RING

1шт.

20

1433 609 H1

SENSOR, MAGNETIC PICKUP

1шт.

21

1433 610 H1

COVER

1шт.

22

103 339

WASHER, FLAT

2шт.

23

120 380

WASHER, LOCK

2шт.

24

81 998

BOLT

2шт.

25

HARNESS, ENGINE WIRING (SEE PG 08-002)

-29шт.
