Запчасти Komatsu GD530A ДВИГАТЕЛЬ ЭЛЕКТРОПРОВОДКА ЭЛЕКТР.

1

ALTERNATOR (SEE PG 08-026)

-29шт.

2

1216 162 H1

SENDING UNIT, ENGINE WATER TEMPERATURE

1шт.

3

1436 865 H91

HARNESS, ENGINE WIRING

1шт.

4

299 407 C1

CLAMP, CABLE

1шт.

5

299 614 C1

CLAMP, CABLE

1шт.

|$5

30 041 R1

BOLT

1шт.

|$6

25 536 R1

WASHER, FLAT

1шт.

6

ELBOW, SPECIAL - 90° (SEE PG 08-054)

-29шт.

7

MOTOR, CRANKING (SEE PG 08-020)

-29шт.

8

SENDING UNITS, TRANSMISSION (SEE PG 08-054)

-29шт.

9

WIRING HARNESS, MAIN - TO REAR (SEE PG 08-006)

-29шт.

10

141 453 H1

CLAMP, CABLE

2шт.

|$12

25 536 R1

WASHER, FLAT

2шт.

11

1437 826 H92

HARNESS, MAIN WIRING

1шт.

12

130 096

CLAMP, CABLE

1шт.

|$15

105 899

STUD, WELD

1шт.

|$16

25 534 R1

WASHER, FLAT

1шт.

|$17

25 522 R1

NUT, HEX

1шт.

13

FILTER, CONVERTER OIL (SEE PG 07-014)

-29шт.

14

299 404 C1

CLAMP, CABLE

1шт.

15

1207 387 H2

SWITCH, MAGNETIC

1шт.

|$21

28 448 R1

BOLT

2шт.

|$22

120 392

WASHER, FLAT

2шт.

|$23

25 519 R1

NUT, HEX

2шт.

16

1434 203 H1

DIODE

1шт.

17

SENDING UNITS, ENGINE OIL PRESSURE (SEE PG 08-054)

-29шт.

18

SWITCH, ENGINE WATER TEMPERATURE (SEE PG 08-054)

-29шт.

19

299 565 C1

CLAMP, CABLE - MAIN HARNESS

6шт.

|$28

136 055

CLAMP, CABLE - MAIN HARNESS

4шт.

|$29

105 899

STUD, WELD

10шт.

|$30

25 534 R1

WASHER, FLAT

10шт.

|$31

25 522 R1

NUT, HEX

10шт.

20

299 399 C1

CLAMP, CABLE

1шт.

|$33

37 467

STUD, WELD

1шт.

|$34

25 532 R1

WASHER, FLAT

1шт.

|$35

25 519 R1

NUT, HEX

1шт.

21

SENDING UNIT, ARTICULATION (SEE PG. 08-056)

1шт.
