Запчасти Komatsu GD530A ШАТУН И ПОРШЕНЬ БЛОК ЦИЛИНДРОВ

1

1240 181 H92

ROD, ENGINE CONNECTING

6шт.

2

1240 150 H1

BOLT, CONNECTING ROD CAP (MJ11x1.25x59)

2шт.

8

1294 387 H1

BUSHING

1шт.

3

1240 170 H1

BEARING, CONNECTING ROD (STD)

2шт.

|$4

1240 570 H1

BEARING, CONNECTING ROD (0.25mm OVERSIZE)

-2шт.

|$5

1240 571 H1

BEARING, CONNECTING ROD (0.50mm OVERSIZE)

-2шт.

|$6

1240 572 H1

BEARING, CONNECTING ROD (0.75mm OVERSIZE)

-2шт.

|$7

1240 573 H1

BEARING, CONNECTING ROD (1.00mm OVERSIZE)

-2шт.

|$8

6735-31-2140

KIT, ENGINE PISTON (STD, COMP RATIO 17.3)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

1240 182 H1

RING, RETAINING

2шт.

6

6732-31-2300

SET, PISTON RING

1шт.

7

1240 185 H1

PIN, PISTON

6шт.

|$13

1310 440 H91

KIT, ENGINE PISTON (0.50mm OVERSIZE)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

1240 182 H1

RING, RETAINING

2шт.

6

6732-39-2300

SET, PISTON RING

1шт.

|$17

1310 441 H91

KIT, ENGINE PISTON (1.00mm OVERSIZE)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

1240 182 H1

RING, RETAINING

2шт.

6

6732-38-2300

SET, PISTON RING

1шт.

|$24

-1шт.

|$22

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$23

ASSEMBLIES CATALOG.

-1шт.
