Запчасти Komatsu GD530A /8 INCH EXTENSION ДЛЯ 7/8 INCH MOLDBOARD ДЛЯ FT. MOLDBOARD КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1434 452 H91

KIT, 2 FT. MOLDBOARD EXTENSION - R.H

1шт.

|$1

1434 444 H91

KIT. 2 FT. MOLDBOARD EXTENSION - L.H

1шт.

1

160 777

PAD, EXTENSION ANGLE

2шт.

2

1286 337 H1

ANGLE, MOLDBOARD EXTENSION

1шт.

3

45 486 A

BOLT, PLOW - DOME HEAD

8шт.

4

25 528 R1

NUT, HEX

19шт.

5

25 537 R1

WASHER, FLAT

19шт.

6

1286 558 H1

PAD, EXTENSION ANGLE

1шт.

7

1286 335 H2

EXTENSION, MOLDBOARD - R.H

1шт.

|$9

1286 336 H2

EXTENSION, MOLDBOARD - L.H

1шт.

8

45 484 A

BOLT, PLOW - DOME HEAD

11шт.

9

45 471

EDGE, CUTTING - 5/8 IN. X 6 IN. X 8 FT

1шт.

10

25 537 R1

WASHER, FLAT - THIN

2шт.

11

25 547 R1

WASHER, FLAT - THICK

2шт.

12

1286 338 H91

ANGLE, MOLDBOARD EXTENSION

1шт.

|$25

-1шт.

|$16

F1 - FOR HEAT-TREATED CUTTING EDGE, ORDER THE FOLLOWING:

-1шт.

|$17

1278 897 H1

EDGE, CUTTING - 5/8 IN. X 6 IN. X 8 FT

1шт.

|$26

-1шт.

|$19

F2 - IF BOTH L.H. AND R.H. EXTENSIONS ARE USED, ONE CUTTING

-1шт.

|$20

EDGE WILL BE 9 FT.

-1шт.

|$21

44 485 A

EDGE, CUTTING - 5/8 IN. X 6 IN. X 9 FT

a

1шт.

|$22

1278 898 H1

EDGE, CUTTING - 5/8 IN. X 6 IN. X 9 FT

b

1шт.

|$27

-1шт.

|$24

F3 - HEAT TREATED.

-1шт.

|$28

-1шт.
