Запчасти Komatsu GD530A АККУМУЛЯТОР ГИДРАВЛS

|$0

1287 649 H92

ACCUMULATOR

-2шт.

1

1286 931 H1

BODY

1шт.

|$2

1286 941 H91

KIT, SEAL

1шт.

2

1286 934 H1

RING, TEFLON

2шт.

3

1286 938 H1

V-RING

1шт.

4

1286 939 H1

O-RING, END CAP

1шт.

5

3046 105 R1

O-RING, GAS VALVE

1шт.

6

1286 933 H1

PISTON

1шт.

7

1286 932 H91

CAP, GAS END

1шт.

8

1286 935 H1

VALVE, GAS

1шт.

9

NSS

CAP, GAS VALVE

1шт.

10

1286 936 H1

PROTECTOR, GAS VALVE

1шт.

11

1286 937 H1

SCREW

2шт.

|$21

-1шт.

|$14

F1 - THE ACCUMULATORS ARE AN OPTION WITH THE CIRCLE

-1шт.

|$15

SHIFT AND BLADE LIFT CYLINDERS. THUS, A POSSIBILITY OF

-1шт.

|$16

FOUR (4) ACCUMULATORS EXIST. EACH ACCUMULATOR IS NOT

-1шт.

|$17

PRECHARGED. SEE THE APPROPRIATE SHOP MANUAL SECTION

-1шт.

|$18

FOR CHARGING INSTRUCTIONS.

-1шт.

|$22

-1шт.

|$20

F2 - INCLUDES O-RING (ITEM 5).

-1шт.

|$23

-1шт.
