Запчасти Komatsu GD530A ОТВАЛ FLOOD LIGHT УСТАНОВКА HALOGEN ОСВЕЩЕНИЕS ЭЛЕКТР.

|$0

1434 004 H91

INSTALLATION, BLADE FLOOD LIGHT

1шт.

1

LAMP, HALOGEN (SEE PG 08-068)

-29шт.

2

1253 070 H1

DAMPER, VIBRATION

2шт.

3

25 750 R1

BOLT, LAMP MOUNTING

2шт.

4

25 533 R1

WASHER, FLAT

2шт.

5

9413 977

NUT, LOCK

2шт.

6

713 142 C1

CABLE

1шт.

7

714 248 C1

BREAKER, CIRCUIT - 10 A

1шт.

8

1106 459 C1

BAR, BUSS

1шт.

9

120 217

WASHER, SPRING LOCK

2шт.

10

120 614

NUT, HEX

2шт.

11

SWITCH, BULB CHECK AND BLADE FLOOD LIGHT (SEE PG 11-002)

1шт.

12

NSS

WIRE 42/DB IN. SWITCH PANEL HARNESS

1шт.

13

BRACKET, CIRCUIT BREAKER (SEE PG 11-002)

-29шт.

14

NSS

WIRE 42/DB IN. MAIN HARNESS

1шт.

15

FRAME (SEE PG 09-002)

-29шт.

15

FRAME (SEE PG 09-004)

-29шт.

15

FRAME (SEE PG 09-006)

-29шт.

15

FRAME (SEE PG 09-008)

-29шт.

15

FRAME (SEE PG 09-010)

-29шт.

15

FRAME (SEE PG 09-012)

-29шт.

N/I

1270 607 H2

BRACKET, LIGHT MOUNTING - USED WITH ALL WHEEL

-1шт.

|$23

DRIVE

2шт.

|$24

25 654 R1

BOLT

2шт.

|$25

120 214

WASHER, LOCK

2шт.

|$26

25 520 R1

NUT, HEX

2шт.

|$29

-1шт.

|$28

F1 - REPLACES MOUNTING HARDWARE INCLUDED WITH LAMP ASSEMBLY.

-1шт.

|$30

-1шт.
