Запчасти Komatsu GD530A ALL КОЛЕСА ПРИВОД ЭЛЕКТРИКА ЭЛЕКТР.

1

PUMP AND TRANSFER CASE (SEE PG 10-108)

-29шт.

2

1433 532 H91

HARNESS, REAR SENSOR

1шт.

3

NSS

WIRE - 1 ALL WHEEL DRIVE

1шт.

4

NSS

WIRE - E ALL WHEEL DRIVE

1шт.

5

NSS

WIRE - 1 ALL WHEEL DRIVE

1шт.

6

NSS

WIRE - F ALL WHEEL DRIVE

1шт.

7

299 406 C1

CLAMP

2шт.

8

1246 048 H1

SENSOR, MAGNETIC PICKUP - REAR

1шт.

9

1259 559 H2

CONTROLLER, ELECTRONIC

1шт.

10

RELAY, REVERSE (SEE PG 08-012)

-29шт.

11

1432 716 H1

RELAY, ALL WHEEL DRIVE DISABLE

1шт.

12

1284 602 H91

HARNESS, FRONT SENSOR

1шт.

13

25 752 R1

BOLT

4шт.

|$13

25 542 R1

WASHER, LOCK

4шт.

14

VALVE, HIC (SEE PG 10-186)

-29шт.

15

386 170 C2

STRAP, TIE

-2шт.

16

1258 753 H1

SENSOR, MAGNETIC PICKUP - FRONT

1шт.

N/I

1430 440 H1

CABLE, JUMPER - FROM AWD FILTER TO HYD FILTER

1шт.
